GE Multilin 369 User Manual

CHAPTER 2: INSTALLATION TERMINAL IDENTIFICATION
369 MOTOR MANAGEMENT RELAY – QUICKSTART GUIDE 2–7
2.2 Terminal Identification
2.2.1 369 Terminal List
TERMINAL WIRING CONNECTION
1RTD1 +
2RTD1 –
3 RTD1 COMPENSATION
4RTD1 SHIELD
5RTD2 +
6RTD2 –
7 RTD2 COMPENSATION
8RTD2 SHIELD
9RTD3 +
10 RTD3 –
11 RTD3 COMPENSATION
12 RTD3 SHIELD
13 RTD4 +
14 RTD4 –
15 RTD4 COMPENSATION
16 RTD4 SHIELD
17 RTD5 +
18 RTD5 –
19 RTD5 COMPENSATION
20 RTD5 SHIELD
21 RTD6 +
22 RTD6 –
23 RTD6 COMPENSATION
24 RTD6 SHIELD
25 RTD7 +
26 RTD7 –
27 RTD7 COMPENSATION
28 RTD7 SHIELD
29 RTD8 +
30 RTD8 –
31 RTD8 COMPENSATION
32 RTD8 SHIELD
33 RTD9 +
34 RTD9 –
35 RTD9 COMPENSATION
36 RTD9 SHIELD
37 RTD10 +
38 RTD10 –
39 RTD10 COMPENSATION
40 RTD10 SHIELD
41 RTD11 +
42 RTD11 –
43 RTD11 COMPENSATION
