4–48 369 MOTOR MANAGEMENT RELAY – QUICKSTART GUIDE
S9 DIGITAL INPUTS CHAPTER 4: KEYPAD SETPOINTS
4.7 S9 Digital Inputs
4.7.1 Digital Input Functions
Description
Any of the digital inputs may be selected and programmed as a separate General Switch,
Digital Counter, or Waveform Capture Input. The xxxxx term in the following menus refers
to the configurable switch input function – either the Spare Switch, Emergency Restart,
Differential Switch, Speed Switch, or Remote Reset inputs described in the following
sections.
General
The above selections will be shown if the in the corresponding menu if SPARE SW
FUNCTION
, EMERGENCY FUNCTION, DIFF SW FUNCTION, or SPEED SW FUNCTION
setpoints are set to “General”. Refer to the individual sections for Spare Switch, Emergency
Restart, Differential Switch, Speed Switch, or Remote Reset below for additional function-
specific setpoints.
xxxxx SW FUNCTION:
General
GENERAL SWITCH
NAME: General
Range: 12 character alphanumeric
Only seen if function is selected as General
MESSAGE
GENERAL SWITCH
TYPE: NO
Range: NO (normally open), NC (normally closed)
Only seen if function is selected as General
MESSAGE
BLOCK INPUT FROM
START: 0 s
Range: 0 to 5000 s in steps of 1
Only seen if function is selected as General
MESSAGE
GENERAL SWITCH
ALARM: Off
Range: Off, Latched, Unlatched
Only seen if function is selected as General
MESSAGE
ASSIGN ALARM RELAYS:
Alarm
Range: None, Alarm, Aux1, Aux2, or combinations
Only seen if function is selected as General
MESSAGE
GENERAL SWITCH
ALARM DELAY: 5.0 s
Range: 0.1 to 5000.0 s in steps of 0.1
Only seen if function is selected as General
MESSAGE
RECORD ALARMS AS
EVENTS: No
Range: No, Yes
Only seen if function is selected as General
MESSAGE
GENERAL SWITCH
TRIP: Off
Range: Off, Latched, Unlatched
Only seen if function is selected as General
MESSAGE
ASSIGN TRIP RELAYS:
Trip
Range: None, Trip, Aux1, Aux2, or combinations
Only seen if function is selected as General
MESSAGE
GENERAL SWITCH
TRIP DELAY: 5.0 s
Range: 0.1 to 5000.0 s in steps of 0.1
Only seen if function is selected as General
