GE NetPro Series User Manual

OPM_NPE_XXX_2K0_4K0_1GB_V040 19 NetPro 2000-4000: user manual 4.0 (GB)
GE Digital Energy
g
NetPro model : 2000 3000 4000
Ratings
Voltage Amperes (VA) : 2000 3000 4000
with computer type load
Watts (W) : 1200 1800 2400
with resistive load
Input thermal circuit breaker (A) : 10 14 16
Input converter
AC input voltage : 220 - 240 V
AC input voltage range : 100% load: 187 - 264 V
60% load: 160 - 264 V
30% load: 125 - 264 V
Maximum start-up AC voltage : 255 V (at any load)
Minimum start-up AC voltage : 187 V (at any load)
Input current waveform : sinusoidal
Input power factor : 1
Input frequency range : 50 or 60 Hz ± 10%
Input current (A) : 6.6 10.0 13.5
Output converter
AC output voltage : 220/230/240 V (selectable)
AC output voltage tolerance : ± 1%
Output frequency : 50 or 60 Hz ± 0.15% unless synchronized to the mains
Output waveform : sine wave
Harmonic distortion : < 2% (typical 1.5%) with linear load
Power factor : 0.6
Crest factor (peak to RMS current) : up to 6:1
Capacity appliance outlets : max. 10 A per outlet
Bypass
AC input voltage range : 187 - 264 V
Frequency tracking rate : max. 2 or 10 Hz/sec.(selectable, factory setting 10Hz/sec)
Frequency tracking rate : 2 Hz/sec 10 Hz/sec
Frequency tracking range : nominal ± 2% nominal ± 10%
Phase difference : < 7° < 10°
Transfer time : < 1 msec.
Overload capability
The UPS is fully protected against overload
Overload behaviour:
on-line operation, bypass enabled : 110% during 5 minutes, 150% during 2 seconds
on-line operation, bypass disabled : 110% during 110 seconds
battery operation, NP2000 : 110% during 5 minutes, >135% during 110 seconds
battery operation, NP3000/4000 : >110% during 110 seconds
bypass operation : depends on rating of thermal circuit breaker; typical
: 105% of TCB value: no trip
135% of TCB value: trip within 1 hour
200% of TCB value: for 2 - 30 secs
300% of TCB value: for 0.8 - 4 secs.
Batteries (ratings given for 25°C)
Nominal voltage (V) : 72 108 120
Number of 7 Ah batteries : 6 9 10
Type : sealed and maintenance free
Service life : 3 - 6 years (depending on use)
Battery recharge current : 1.5 A
Battery recharge time : 2 - 6 hours for 80% capacity, std. battery
Automatic battery test : see 3.6.4
Runtime in minutes
at typical load (75%) : 7 7 7
Watts
60 190 270 310
120 117 165 185
240 60 95 105
360 38 63 72
600 21 35 40
900 13 22 25
1200 9 15 18
1800 - 9 10
General
Weight (kg) : 27 38 42
Dimensions (hxwxd, mm) : 293x220x557
Enclosure / protection : steel-plastic / IP20
Environment
Safety : EN 50091-1-1; EN 60950; IEC 950
Electromagnetic compatibility : EN 50091-2; EN 50081-1 + EN 50082-1; IEC 801-5: 6kV
Ambient temperature : -10 to +40°C
Audible noise at 1 meter : 45 dB(A)
The audible noise is load and temperature dependent
Max. relative humidity : 95% (non-condensing)
8 - Specifications
