8 SPECIFICATIONS
VH Series
:
2000
3000
Ratings
Voltage Amperes (VA) with computer type load
:
2000
3000
Watts (W) with resistive load
:
1800
2700
Input thermal circuit breaker (A)
:
20
20
Internal input fuse 250V, slow (A)
:
20
20
Input converter
AC input voltage
:
120-280V
Input current waveform
:
sinusoidal, EN 61000-3-2 (IEC 555-2) compliant
Input current (A) at nominal input voltage
:
10.4
15.2
Input power factor
:
1
Input frequency range
:
45 - 66 Hz
Inrush current
:
none
Output converter
AC output voltage
:
208 / 220 / 230 / 240 V (selectable)
AC output voltage tolerance
:
± 2%
Output frequency
:
auto selectable or 50 / 60 Hz, front selectable
Output frequency range
:
nominal ± 0.05% unless synchronized to the mains
Output waveform
:
sine wave
Harmonic distortion
:
< 1% with linear load
Power factor
:
0.9
Crest factor (peak to RMS current)
:
suitable for loads with c.f. up to 3:1
Capacity appliance outlets
:
max. 20A per outlet
Bypass
AC input voltage range
:
selected output voltage -15% to +10%
Frequency tracking rate
:
2 Hz/sec.
Frequency tracking range
:
nominal ± 10% / ± 2% selectable
Phase difference
:
< 1º typical (max. 7º during tracking frequency range)
Typical transfer time, msec
:
1
Overload capability
:
fully protected against overload and short circuits
Overload behaviour during battery operation
:
110% 4 minutes
:
150% 2 seconds
Overload behavior during bypass operation
:
depends on rating of thermal circuit breaker
typical:
125% of TCB value for 200 seconds
200% of TCB value for 10 seconds
300% of TCB value for 4 seconds
Batteries (ratings given for 77ºF
Nominal voltage (Vdc)
:
72
72
Number / Ah batteries
:
6 / 7
6 / 9
Type
:
sealed lead acid, maintenance free
Service life
:
up to 6 years (depending on use)
Recharge current
:
1.5 A
Battery recharge time
3 hours for 90% capacity, std battery
(batt. discharged at 100% load)
:
Runtime in minutes at typical load (75%)
:
10
8
VA / Watts
500 / 450
:
44
60
1000 / 900
:
18
27
1500 / 1350
:
10
16
2000 / 1800
:
5
10
2250 / 2025
:
-
8
3000 / 2700
:
-
4
General
Weight UPS (lbs/kg)
:
66 / 30
68 / 31
Dimensions UPS (HxWxD, inch/mm)
:
9.0x7.4x23.4 inch / 228x188x595 mm
Enclosure / protection
:
steel-plastic / IP20
Battery pack
Nominal Voltage (Vdc)
:
72
Max. number / Ah battery extension pack
:
3 / 14
Weight (lbs/kg)
:
88 / 40
Dimensions (HxWxD, inch/mm)
:
9.0x7.4x23.6 inch / 228x188x600 mm
:
Environment
Safety
:
UL 1778, 5
th
Edition
Electromagnetic compatibility
:
EN 62040-2
Ambient temperature
:
32 to 104ºF (0 to +40ºC)
Audible noise at 1 meter
:
< 45 dB(A), load and temperature dependent
Max. relative humidity
:
95% (non-condensing)
