6.2 METERING
The METERING mode is entered any time the “METER” button is pressed.
The LCD screen will indicate a series of screenshots showing the measures of all electric parameters like
AC, DC and various statistics.
In this mode the buttons perform the following functions:
Return to HOME screen.
Scrolls backward to the previous screen.
Scrolls forward to the next screen.
It is possible to view any pushbutton functional description by pushing the button for more than 3
seconds.
`Home\Meter
BATTERY
V 545 V
I 50.0 A
T +25° C
Charge level 80 %
Autonomy 10 Min
Battery data screen
V The battery voltage.
I The battery current (negative values correspond to
the discharge of the battery).
T The temperature of the battery (“SENSOR DISABLE”
indicates sensor disabled).
Charge level The battery charge level.
Autonomy The estimated backup time with the
present load.
`Home\Meter
RECTIFIER
f :
60.0 Hz
L12 :
480 V Vdc : 540 V
L23 :
480 V Idc1 : 250.0 A
L31 :
480 V Idc2 : 250.0 A
Rectifier utility data screen
f The input frequency of the rectifier.
L12
L23 The voltage levels between the three phases (line-
L31 to-line).
Vdc Rectifier voltage output.
Idc1 Output current 1
st
Rectifier bridge.
Idc2 Output current 2
nd
Rectifier bridge.
`Home\Meter
UTILITY
f 60 Hz
L1 275 V
L2 279 V
L3 276 V
BYPASS FREE
Bypass utility data screen
f The frequency of the utility.
L1
L2 Three-phase utility voltage PHASE /NEUTRAL.
L3
Bypass Bypass status: FREE / LOCKED.
