6.4 SETUP
The SETUP mode is entered any time the “SETUP” button is pressed.
This screen allows the user to modify some parameters permitting to adapt some functions of the UPS
to his/her needs, described as follows.
The LCD will display a series of screens containing the user parameters, accessible without password
protection.
In this mode the buttons perform the following functions:
Return to HOME screen.
Scrolls backward to the previous screen.
Scrolls forward to the next screen.
Confirm selected choice of USER / SERVICE level.
Description of the pushbutton to set or modify the parameters:
ESC
Allows to exit a selected screen without making any modification.
U
Scrolls backward to the previous line.
V
Scrolls forward to the next line.
Allows to access a value to be set or modified.
Select, on the same line, the following value or letter to set or modify.
Set or modify the selected value.
Save the set or modified value and return to the selected screen.
It is possible to view any pushbutton functional description by pushing the button for more than 3
seconds.
`Home\Setup
UPS IDENTIFICATION
ID : UPS 0
Model : SG Series S2 300
S/N : P2300-2010-0001
UPS SW Version : xxx
Display SW Version : xxx
UPS identification screen
ID Number of UPS in the RPA Parallel System (0
for single unit).
Model UPS model, series number and power range
S/N The UPS serial number.
UPS SW The UPS software version.
Display SW The LCD display software version.
To Next Page
