GE SX Series User Manual

RS-232 MEMORY MAP TABLES
SX TRANSISTOR CONTROL Page 67
Revised May 2003
Section 7.0 TRACTION CONTROL MEMORY MAP
E
2
Func No. HS
No.
Traction Control
Function
Access By Restrictions
0 1 1 MPH Scaling HS or PC None
1 2 2 Creep HS or PC None
2 3 3 Controlled Acceleration HS or PC None
3 4 4 Speed Regulation/Dec. Field HS or PC None
4 5 5 Pot/Directional Calibration HS or PC None
5 6 6 MPH BL3C Speed Limit HS or PC None
6 7 7 Overspeed Response HS or PC None
7 8 8 Maximum Field Current HS or PC None
8 9 9 Regen BrakingCurrent Limit HS or PC None
9 10 10 Field Current for Regen HS or PC None
10 11 11 Maintenance and Lost Tach Speed Limit or
Park Brake Switch Closed
HS or PC None
11 12 12 Max Percent On HS or PC None
12 13 13 Speed Limit 3 HS or PC None
13 14 14 IR Compensation HS or PC None
14 15 15 Battery Volts Select HS or PC None
15 16 16 Stall MPH HS or PC None
16 17 17 Card Type Select HS or PC None
17 18 18 Line Driver Time Delay HS or PC None
18 19 19 Maintenance Code HM (Tens/Units) HS or PC None
19 20 20 Maintenance Code HM (Thou/Hun) HS or PC None
20 21 21 Auto Regen HS or PC None
21 22 22 Not applicable HS or PC For DD on power up
22 23 23 Plug/Regen Transition HS or PC None
23 24 24 Field Weakening Start HS or PC None
24 25 25 Monitor HS or PC GE Temporary Storage
25 26 26 Ratio HS or PC GE Temporary Storage
26 27 27 Not applicable HS or PC GE Temporary Storage
27 28 28 Stored Status Code Count Pointer HS or PC None
28 29 29 Not applicable HS or PC None
29 30 30 Not applicable HS or PC None
30 31 Aux HM (Tens/Ones) PC Only None
31 32 Aux HM (Thou/Hun) PC Only None
32 33
(18)
Stored Status Code #1 PC Only Reset to Zero Only
33 34 BDI 1 PC Only Reset to Zero Only
34 35 Hours (Tens/Ones) 1 PC Only Reset to Zero Only
35 36 Hours (Thou/Hun) 1 PC Only Reset to Zero Only
36 37
(20)
Stored Status Code #2 PC Only Reset to Zero Only
37 38 BDI 2 PC Only Reset to Zero Only
38 39 Hours (Tens/Ones) 2 PC Only Reset to Zero Only
39 40 Hours (Thou/Hun) 2 PC Only Reset to Zero Only
40 41
(22)
Stored Status Code #3 PC Only Reset to Zero Only
41 42 BDI 3 PC Only Reset to Zero Only
42 43 Hours (Tens/Ones) 3 PC Only Reset to Zero Only
