2.3. Specifications
Basic specifications, 200V series
Type No: VAT20-
U20N0K2_ U20N0K4_ U20N0K7_ U20N1K5_ U20N2K2_
Suitable Motor Power Rating (kW) 0.2 0.4 0.75 1.5 2.2
Motor HP 1/4 1/2 1 2 3
Current A 1.4 2.3 4.2 7.5 10.5
Capacity kVA 0.53 0.88 1.6 2.9 4.0
Rated
Weight (kg ) 0.76 0.77 0.8 1.66 1.76
Input Voltage Max. Single phase 200/240V (+10% -15%),
50/60Hz (±5%)
Single/Three phases
200-240V (+10% -15%),
50/60Hz (±5%)
Output Voltage Max. Three phase 200/240V +10%-15%
Dimensions (W x H x D) mm 72x132x118 118x143x172
EMC specification
(1)
Class A (single phase filter built in)
(1) Only for U20N_K_S type
Basic specifications, 400V series
Type No: VAT20-
U20X0K7_ U20X1K5_ U20X2K2_
Suitable Motor Power Rating (kW) 0.75 1.5 2.2
Motor HP 1 2 3
Current A 2.3 3.8 5.2
Capacity kVA 1.6 2.9 4.0
Rated
Weight (kg ) 1.66 1.66 1.76
Input Voltage Max. Three phase 380/460V (+10% -15%), 50/60Hz (± 5%)
Output Voltage Max. Three phase 380/460V +10%-15%
Dimensions (W x H x D) mm 118x143x172
EMC specification
(2)
Class A (single phase filter built in)
(2) Only for U20X_K_S type
