gefran 650 Series User Manual

1212
POWER SUPPLY 100...240 VAC
Code F Model
Valves Programmer
Inputs Outputs
RS485 Logic functions
Total Number of Outputs
Digital CT Remote SP Relay Triac Logic Analog I Analog V/I
F060558 650-D-R00-00000-1-G 1 1
2 outputsF059574 650-R-R00-00000-1-G 2
F060566 650-D-R00-00120-1-G 2 1 1 1
F060562 650-D-RR0-00000-1-G 2 1
3 outputs
F065788 650-R-RR0-00000-1-G 3
F065789 650-R-TR0-00000-1-G 2 1
F065790 650-D-RR0-00030-1-G 3 2 1
F060567 650-D-RR0-00200-1-G 2 2 1
F060564 650-C-RR0-00000-1-G 2 1
F060573 650-D-R00-01030-1-G 3 1 1 1
F065791 650-R-R00-01030-1-G 3 2 1
F060574 650-R-RR0-00101-1-G 1 3 •
F060563 650-D-RRR-00000-1-G 3 1
4 outputs
F065792 650-R-RRR-00000-1-G 4
F060575 650-D-RRR-00220-1LFG 2 2 3 1 •
F060576 650-D-RRR-00031-1LFG 3 3 1 • •
F065793 650-D-RRR-00201-1LFG 2 3 1 • •
F065794 650-D-RR0-01011-1LFG 1 2 1 1 • •
F060577 650-C-RR0-10030-1LFG 3 1 3 1 •
F060578 650V-R-RRR-00000-1-G • 4
F060561 650V-R-RRR-00030-1-G • 3 4
F060565 650P-D-RRR-00000-1-G • 3 1
F060560 650P-D-RRR-00030-1LFG • 3 3 1 •
F060579 650-D-RRR-01030-1LFG 3 3 1 1 • 5 outputs
ORDER METHODS 650

gefran 650 Series Specifications

General

Category	Controller
Display	LCD
Inputs	Thermocouple
Outputs	Digital and Analog
Power Supply	24V DC
Communication	RS485
Control Mode	PID, On/Off
Mounting	Panel
Protection Rating	IP65 (front)

Summary

MUCH MORE THAN A SIMPLE CONTROLLER

FLEX-VIEW DISPLAY

Customizable display options including color, messages, and bargraph for enhanced user interface.

EASY AND FAST SETUP

Offers three configuration methods: keyboard, PC software, and portable configurator for quick setup.

FLEX-VIEW DISPLAY

CUSTOM LABELING

MESSAGES ON DISPLAY

EASY SET UP

Seven-Step Keyboard Configuration

A guided 7-step process for initial controller setup via the keyboard, requiring no user manual.

CONFIGURATION WITH GF_eXpress AND Zapper

PC Configuration via GF_eXpress

Utilizes PC software and USB connection for efficient parameter copying and pasting.

Portable Configuration with Zapper

Employs a battery-powered portable configurator connected via microUSB for parameter transfer.

SETPOINT PROGRAMMER

Energy Monitor Functionality

Preventive Maintenance Alerts
