2.2 Standard Product Specification
Model
Supply
Voltage
(Vac)
Frequency
(Hz)
(HP)
(kW)
Model EMC Filter
Braking
Unit
NPN PNP Built-in None
Built-in
BDI50-1004-KXX-2M-N
1ph,
200~240V
+10%/-15%
50/60Hz
0.5 0.4
◎ ◎
BDI50-1007-KXX-2M-N
1 0.75
◎ ◎
BDI50-2015-KXX-2M-N
2 1.5
◎ ◎
BDI50-2022-KXX-2M-N
3 2.2
◎ ◎
BDI50-1004-KXX-2M-P-F
0.5 0.4
◎ ◎
BDI50-1007-KXX-2M-P-F
1 0.75
◎ ◎
BDI50-2015-KXX-2M-P-F
2 1.5
◎ ◎
BDI50-2022-KXX-2M-P-F
3 2.2
◎ ◎
BDI50-1007-KXX-2T-N
3ph,
200~240V
+10%/-15%
50/60Hz
1 0.75
◎ ◎
BDI50-2015-KXX-2T-N
2 1.5
◎ ◎
BDI50-2022-KXX-2T-N
3 2.2
◎ ◎
BDI50-3037-KBX-2T-NP
5 3.7
◎ ◎ ◎ ◎
BDI50-4055-KBX-2T-NP
8 5.5
◎ ◎ ◎ ◎
BDI50-4075-KBX-2T-NP
10 7.5
◎ ◎ ◎ ◎
BDI50-2007-KBX-4-N
3ph,
380~480V
+10%/-15%
50/60Hz
1 0.75
◎ ◎ ◎
BDI50-2015-KBX-4-N
2 1.5
◎ ◎ ◎
BDI50-2022-KBX-4-N
3 2.2
◎ ◎ ◎
BDI50-3037-KBX-4-NP
5 3.7
◎
◎
◎ ◎
BDI50-3055-KBX-4-NP
8 5.5
◎ ◎ ◎ ◎
BDI50-4075-KBX-4-NP
10 7.5
◎
◎
◎ ◎
BDI50-4110-KBX-4-NP
15 11
◎ ◎ ◎ ◎
BDI50-2007-KBX-4-P-F
1 0.75
◎ ◎ ◎
BDI50-2015-KBX-4-P-F
2 1.5
◎ ◎ ◎
BDI50-2022-KBX-4-P-F
3 2.2
◎ ◎ ◎
BDI50-3037-KBX-4-NP-F
5 3.7
◎ ◎ ◎ ◎
BDI50-3055-KBX-4-NP-F
8 5.5
◎
◎
◎ ◎
BDI50-4075-KBX-4-NP-F
10 7.5
◎ ◎ ◎ ◎
BDI50-4110-KBX-4-NP-F
15 11
◎
◎
◎ ◎
Short circuit capacity is below 5000A/240V or 5000A/480V.
The voltage for 200~240V models is 240V, 380~480V models is 480V.
