Specifications
Voltage Class 230V Class Single phase
Model Number ADV50-XXXX 1004 1007 2015 2022
Max. Applicable Motor Output (kW) 0.4 0.75 1.5 2.2
Max. Applicable Motor Output (Hp) 0.5 1.0 2.0 3.0
Rated Output Capacity (kVA) 1.0 1.6 2.9 4.2
Rated Output Current (A) 2.5 4.2 7.5 11.0
Maximum Output Voltage (V)
3-Phase Proportional to Input Voltage
Output Frequency (Hz)
0.1~600 Hz
Output Rating
Carrier Frequency (kHz)
1-15
Single phase
Rated Input Current (A)
6.5 9.5 15.7 24
Rated Voltage/Frequency Single phase 200-240 V, 50/60Hz
Voltage Tolerance
±
10%(180~264 V)
Input Rating
Frequency Tolerance
±
5%(47~63 Hz)
Cooling Method Natural Cooling Fan Cooling
Weight (kg) 1.1 1.1 1.9 1.9
Voltage Class 230V Class 3 - phase
Model Number ADV50-XXXX 1007 1015 2022 2037 3055 3075
Max. Applicable Motor Output (kW) 0.75 1.5 2.2 3.7 5.5 7.5
Max. Applicable Motor Output (Hp) 1.0 2.0 3.0 5.0 7.5 10
Rated Output Capacity (kVA) 1.6 2.9 4.2 6.5 9.5 12.5
Rated Output Current (A) 4.2 7.5 11.0 17 25 33
Maximum Output Voltage (V)
3-Phase Proportional to Input Voltage
Output Frequency (Hz)
0.1~600 Hz
Output Rating
Carrier Frequency (kHz)
1-15
3-phase
Rated Input Current (A)
5.1 9 15 20.6 26 34
Rated Voltage/Frequency 3-phase 200-240 V, 50/60Hz
Voltage Tolerance
±
10%(180~264 V)
Input Rating
Frequency Tolerance
±
5%(47~63 Hz)
Cooling Method
Natural
Cooling
Fan Cooling
Weight (kg) 1.1 1.2 1.9 1.9 3.5 3.5
Voltage Class 400V-460V Class (Power ratings at 400V)
Model Number ADV50-XXXX 1004 1007 1015 2022 2037 3055 3075 3110
Max. Applicable Motor Output (kW) 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11
Max. Applicable Motor Output (Hp) 0.5 1.0 2.0 3.0 5.0 7.5 10 15
Rated Output Capacity (kVA) 1.2 2.0 3.3 4.4 6.8 9.9 13.7 18.3
Rated Output Current (A) 1.5 2.5 4.2 5.5 8.2 13 18 24
Maximum Output Voltage (V)
3-Phase Proportional to Input Voltage
Output Frequency (Hz)
0.1~600 Hz
Output Rating
Carrier Frequency (kHz) 1-15
3-phase
Rated Input Current (A)
1.9 3.2 4.3 7.1 11.2 14 19 26
Rated Voltage/Frequency 3-phase, 380-480V, 50/60Hz
Voltage Tolerance
±
10%(342~528V)
Input Rating
Frequency Tolerance
±
5%(47~63Hz)
Cooling Method Natural Cooling Fan Cooling
Weight (kg) 12 1.2 1.2 1.9 1.9 4.2 4.2 4.2
