Generac Power Systems RXUW200A3 User Manual

Drawings and Diagrams
Automatic Transfer Switch Owner’s Manual 23
No. A0000258228-A (Part 2 of 2)—Air-Cooled Generator
N1
N2
N1
N2
T1 T2 E1 E2
UTILITY SUPPLY
ELECTRODE
TO GROUNDING
GROUND CONNECTION
NEUTRAL CONNECTION
OPTIONAL
5TH JAW KIT
SOLAR CONNECTION
NEUTRAL BOND
DISTRIBUTION PANEL
(CUSTOMER LOAD)
GENERATOR CUSTOMER CONNECTION
NEUTRAL BAR
0
GROUND BAR
N1
N2
T1
194
23
GROUND CONNECTION
NEUTRAL CONNECTION
E1
E2
194
23
N1 N2
T1
0
23 TRANSFER 194 +12V 0 GROUND N2 N1 T1 2 1 2 1 2
A/C 4 A/C 3
N2 N1
SERVICE ENTRANCE SWITCH INTERCONNECT
NOTE: INSTALLATION MUST MEET ALL NATIONAL, STATE, AND LOCAL ELECTRIC CODES.
