Operator’s Manual for Portable Generator 9
4. Add recommended engine oil.
NOTE: Some units have more than one oil
fill location. It is only necessary to use one
oil fill point.
5. Thread dipstick into oil filler neck. Oil level
is checked with dipstick fully installed.
6. See Figure 2-14. Remove dipstick and ver-
ify oil level is within safe operating range.
7. Install oil fill cap/dipstick and hand-tighten.
Figure 2-14. Safe Operating Range
Fuel
IMPORTANT! DO NOT use Home Heating Oil
or Bio-Diesel Fuel.
Use No. 2D diesel fuel when temperatures are
above freezing. When temperatures are below
freezing, blend No.1D diesel fuel and No. 2D
diesel fuel together for a climate adjusted fuel
ratio.
Diesel fuel must meet the following require-
ments:
• Sulfur content of 15 parts per million (ppm)
maximum.
• Minimum Cetane index of 40.
NOTE: Low ambient temperatures as well
as engine operation at high altitudes may
require the use of fuels with higher Cetane
ratings.
Fuel Maintenance
• Always treat diesel fuel for long term stor-
age. Use the approved fuel additive and
water abatement material. Test stored fuel
every 90 days and provide additional treat-
ment if required. Periodically check and dry
abatement material as necessary.
(000105)
DANGER
Explosion and Fire. Fuel and vapors are extremely
flammable and explosive. Add fuel in a well
ventilated area. Keep fire and spark away. Failure to
do so will result in death or serious injury.
(000166)
DANGER
Do not overfill fuel tank. Fill to 1/2 in. of top of tank to
allow for fuel expansion. Overfilling may cause fuel to
spill onto engine causing fire or explosion, which will
result in death or serious injury.
