210 ONE MAN HOLE DIGGER, FORM GOM-1061-1189, VERSION 2.0, AUTHORIZATION: DVR, PAGE: 23
Open vent.
Dirty air filter. See Service section.
ENGINE OVERHEATS
Incorrect carburetor adjustment. See Service section.
Incorrect fuel/oil mixture ratio. See Before Starting
The Engine section.
Cooling fins clogged. Remove engine blower housing
and clean cooling fins.
OPERATIONAL PROBLEMS.
HOLE DIGGER LACKS POWER
Incorrect amount of transmission lubricant. See
Service section.
Centrifugal clutch assembly worn. Replace
Auger diameter too large for given soil condition. See
Digging Operation section.
Incorrect throttle control/cable adjustment. See
Assembly section.
AUGER ROTATES AT IDLE SPEED
Incorrect throttle control/cable adjustment does not
permit proper engine idle speed. See Assembly
section.
Centrifugal clutch worn. Replace.
Incorrect engine idle speed. See Service section.
Storage
Proper procedure for long term storage of the Hole
Digger will protect it against the affects of corrosion
and damage. If the Hole Digger is not to be operated
for a period of 30 days or more, proceed to store as
follows:
1) Clean all accumulated dirt and grease from the Hole
Digger utilizing an approved safety solvent.
Observe all applicable safety precautions for the
solvent
2) Follow the procedure as outlined in the material
supplied by the engine manufacturer detailing long
term storage of the engine.
3) Check all visible parts for wear, breakage or
damage. Order any part required to make the
necessary repair. This will avoid a needless delay
when operating the Hole Digger at next use.
4) Apply a light coat of protective grease to the
transmission final driveshaft to prevent the formation of
rust.
5) Do not store the Hole Digger connected to an auger.
Always store the Hole Digger with the operator handle
level with the ground.
6) Store the Hole Digger inside. If the Hole Digger must
be stored outside, protect it and each auger with a
suitable covering.
Specifications
ENGINE.
TYPE Tecumseh TC300
HIGH SPEED 6000 RPM (No Load)
IDLE SPEED 2500 RPM
SPARK PLUG GAP .030 inch (.76 mm)
FUEL Unleaded (Regular grade is an
acceptable substitute) grade gasoline and SAE 30 or
40 weight non detergent oil or a high quality 2 cycle oil
mixed in a 24 to 1 mixture ratio. Consult the material
supplied by the engine manufacturer for more specific
information.
GASOLINE TANK 16 US ounces (0.5 liter)
CAPACITY
TYPE Tecumseh TM049
To Next Page
