OUTDOOR UNIT
2013.02.15 2
DIMENSIONS
(Unit : mm)
INDOOR UNIT
31 12330 mm
900 mm
9
21
1290 mm
650 mm
400 mm
370 mm
air flow
699 (Hanging bolt position)
890 (Ceiling opening measurement
795 (Hanging bolt position)
950 (Panel measurement)
Drain pipe
840 mm
699 mm
DECORATION PANEL
Liquid pipe
Gas pipe
288
358
795 mm
338
60
130
170
133
190
