BIOS Configuration
4-23
• IRQ (7,12,14,15), IRQ(3,4,5,9,10,11)&DMA(0,1,3,5,6,7) assigned to
The default value is "Legacy ISA" or "PCI/ISA PnP".
Legacy ISA The resource is used by Legacy ISA device.
PCI/ISA PnP The resource is used by PCI/ISA PnP device (PCI or
ISA).
• PCI IRQ Actived By
The default value is Level.
Level Set PCI IRQ Actived by Level.
Edge Set PCI IRQ Actived by Edge.
• PCI IDE IRQ Map To
The default value is PCI-AUTO.
PCI-AUTO Map PCI IDE IRQ to PCI slot automatically.
ISA Map PCI IDE IRQ to ISA slot.
•
Primary/Secondary IDE INT#
A Set INTA for primary/secondary PCI IDE.
B Set INTB for primary/secondary PCI IDE.
C Set INTC for primary/secondary PCI IDE.
D Set INTD for primary/secondary PCI IDE.
