5AX
25
SOFT PWR : Power On/Off Switch
CPU
1
M1541
M1543
5AX
system immediately
1. Instant On/
Off:Power On/Off
2. Delay 4
Seconds:Power. Off
system
.Press over 4
Secs
Two Option :
1
ATX Power Connector
CPU
1
M1541
M1543
5AX
1
11
Pin No.
Definition
3,5,7,13,15-17
GND
1,2,11
3.3V
4,6,19,20
VCC
10
+12V
12
-12V
18
-5V
8
Power Good
9
5V SB (stand by+5V)
14
PS-ON(Soft On/Off)
JP1 : CPU Cooling Fan P
ower Connector
CPU
1
M1541
M1543
5AX
1
Pin No.
Function
1
2
GND
+12V
3
SENSE
26
28
