Gigabyte AORUS MASTER Z490 User Manual

- 24 -
Hardware Installation
Quick Button
This motherboard has 2 quick buttons: power button and reset button. The power button and reset button allow
users to quickly turn on/off or reset the computer in an open-case environment when they want to change
hardware components or conduct hardware testing.
PW_SW: Power Button
RST_SW: Reset Button
RST_SW
Voltage Measurement Points
Use a multimeter to measure the following motherboard voltages.
PW_SW
VCCIO VCCSA VCORE DDRVTT PCH_CORE DDRVPP VDDR VAXG
+ + + + + + + +
