- 30 -
This motherboard incorporates cable diagnostic feature designed to detect the status of the attached LAN cable.
This feature will detect cabling issue and report the approximate distance to the fault or short.
SMART LAN
CMOS Setup Utility-Copyright (C) 1984-2012 Award Software
SMART LAN
Start detecting at Port.....
Part1-2 Status = Open / Length = 0m
Part3-6 Status = Open / Length = 0m
Part4-5 Status = Open / Length = 0m
Part7-8 Status = Open / Length = 0m
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level 
OnChip SATA Port as ESP
CMOS Setup Utility-Copyright (C) 1984-2012 Award Software
OnChip SATA Port as ESP
Port0 as ESP [Disabled]
Port1 as ESP [Disabled]
Port2 as ESP [Disabled]
Port3 as ESP [Disabled]
x Port4 as ESP Disabled
x Port5 as ESP Disabled
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level 
Port0 as ESP/Port1 as ESP/Port2 as ESP/Port3 as ESP
 ThisoptioniscongurableonlywhenOnChip SATA Type is set to AHCI. Enabled will speed up the hot
plug detection of the connected SATA device. (Default: Disabled)
Port4 as ESP/Port5 as ESP
This option is configurable only when OnChip SATA Type is set to AHCI and OnChip SATA Type
Port4/5 is set to As SATA Type. Enabled will speed up the hot plug detection of the connected SATA
device. (Default: Disabled)
Onboard LAN Function
Enables or disables the onboard LAN function. (Default: Enabled) If you wish to install a 3rd party add-in
network card instead of using the onboard LAN, set this item to Disabled.
Onboard LAN Boot ROM
Allows you to decide whether to activate the boot ROM integrated with the onboard LAN chip.
(Default: Disabled)
Onboard Audio Function
Enables or disables the onboard audio function. (Default: Enabled)
If you wish to install a 3rd party add-in audio card instead of using the onboard audio, set this item to
Disabled.
USB Controllers
Enables or disables the integrated USB controllers. (Default: Enabled)
Disabled will turn off all of the USB functionalities below.

Gigabyte GA-78LMT-S2 Specifications

General

Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X4, AMD Phenom II X6
Maximum number of SMP processors	1
Power fan connector	Yes
Number of SATA II connectors	6
Number of SATA III connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	4
Component for	PC
Power source type	ATX
Motherboard chipset	AMD 760G
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Motherboard southbridge	AMD SB710
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	SATA
Parallel processing technology support	Not supported
ACPI version	1.0b
Ethernet interface type	Fast Ethernet, Gigabit Ethernet

Weight and Dimensions

Depth	188 mm
Width	244 mm
