Gigabyte GA-78LMT-S2 User Manual

- 8 -
1-2 ProductSpecications
CPU
 AM3+ Socket:
- AMD AM3+ processor
- AMD AM3 Phenom
™
II processor/ AMD Athlon
™
II processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper
Transport 3.0

4400 MT/s
Chipset

North Bridge: AMD 760G

South Bridge: AMD SB710
Memory

2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
* Due to a Windows 32-bit operating system limitation, when more than 4 GB of
physical memory is installed, the actual memory size displayed will be less than
the size of the physical memory installed.

Dual channel memory architecture

Support for DDR3 1333+ (O.C.)/1066 MHz memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and
memory modules.)
Onboard
Graphics

North Bridge:
- 1 x D-Sub port
Audio

Realtek
ALC887
audio codec

HighDenitionAudio

2/4/5.1/7.1-channel
* Tocongure7.1-channelaudio,youhavetouseanHDfrontpanelaudiomodule
and enable the multi-channel audio feature through the audio driver.
LAN

Realtek GbE LAN chip (10/100/1000 Mbit)
Expansion Slots

1 x PCI Express x16 slot, running at x16

1 x PCI Express x1 slot
(The PCI Express slots conform to PCI Express 2.0 standard.)

1 x PCI slot
Storage Interface

South Bridge:
- 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
- Support for RAID 0, RAID 1, RAID 10, and JBOD
USB

South Bridge:
- Up to 8 USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available
through the internal USB headers)

Gigabyte GA-78LMT-S2 Specifications

General

Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X4, AMD Phenom II X6
Maximum number of SMP processors	1
Power fan connector	Yes
Number of SATA II connectors	6
Number of SATA III connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	4
Component for	PC
Power source type	ATX
Motherboard chipset	AMD 760G
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Motherboard southbridge	AMD SB710
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	SATA
Parallel processing technology support	Not supported
ACPI version	1.0b
Ethernet interface type	Fast Ethernet, Gigabit Ethernet

Weight and Dimensions

Depth	188 mm
Width	244 mm
