Gigabyte GA-78LMT-S2 User Manual

- 29 -
2-6 Integrated Peripherals
CMOS Setup Utility-Copyright (C) 1984-2012 Award Software
Integrated Peripherals
OnChip SATA Controller [Enabled]
OnChip SATA Type [Native IDE]
x OnChip SATA Port4/5 Type IDE
x OnChip SATA Port as ESP Press Enter
Onboard LAN Function [Enabled]
Onboard LAN Boot ROM [Disabled]
 SMART LAN [Press Enter]
Onboard Audio Function [Enabled]
USB Controllers [Enabled]
USB Legacy Function [Enabled]
USB Storage Function [Enabled]
Onboard Serial Port [3F8/IRQ4]
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level 
Init Display First
 Speciestherst initiationofthemonitordisplayfromtheinstalledPCI graphicscard,PCIExpress
graphics card, or the onboard graphics.
PCISlot  SetsthePCIgraphicscardastherstdisplay.(Default)
OnChipVGA Setstheonboardgraphicsastherstdisplay.
PEG   SetsthePCIExpressgraphicscardonthePCIEX16slotastherstdisplay.
OnChip SATA Controller
Enables or disables the integrated SATA controller. (Default: Enabled)
OnChip SATA Type (SATA2 0~SATA2 3 connectors)
 CongurestheoperatingmodeoftheintegratedSATA20~SATA23controller.
Native IDE Allows the SATA controller to operate in Native IDE mode. (Default)
Enable Native IDE mode if you wish to install operating systems that support Native
mode.
RAID Enables RAID for the SATA controller.
AHCI   CongurestheSATAcontrollerstoAHCImode.AdvancedHostControllerInterface
     (AHCI)isaninterfacespecicationthatallowsthestoragedrivertoenableadvanced
Serial ATA features such as Native Command Queuing and hot plug.
OnChip SATA Port4/5 Type (SATA2 4/SATA2 5 connectors)
This option is configurable only when OnChip SATA Type is set to RAID or AHCI. Configures the
operating mode of the integrated SATA2 4/SATA2 5 connectors.
IDE   DisablesRAIDfortheSATAcontroller and congurestheSATAcontrollertoPATA
mode. (Default)
As SATA Type The mode depends on the OnChip SATA Type settings.
