- 22 -
2-3 MB Intelligent Tweaker(M.I.T.)
Whether the system will work stably with the overclock/overvoltage settings you made is depen- •
dent on your overall system congurations. Incorrectly doing overclock/overvoltage may result in
damage to CPU, chipset, or memory and reduce the useful life of these components. This page is
for advanced users only and we recommend you not to alter the default settings to prevent system
instability or other unexpected results. (Inadequately altering the settings may result in system's
failure to boot. If this occurs, clear the CMOS values and reset the board to default values.)
When the • System Voltage Optimized item blinks in red, it is recommended that you set the
System Voltage Control item to Auto to optimize the system voltage settings.
(Note) This item is present only when you install a CPU that supports this feature.
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
MB Intelligent Tweaker(M.I.T.)
IGXConguration [PressEnter]
CPUClockRatio [Auto] 2800Mhz
CPU NorthBridge Freq.
[Auto] 2000Mhz
Core Performance Boost
(Note)
[Enabled]
CPB Ratio
(Note)
[Auto] 3100Mhz
TurboCPB
(Note)
[Disabled]
CPUHostClockControl [Auto]
x CPU Frequency(MHz) 200
PCIEClock(MHz) [Auto]
HTLinkWidth [Auto]
HTLinkFrequency [Auto] 2000Mhz
SetMemoryClock [Auto]
x Memory Clock x4.00 800Mhz
DRAMConguration [PressEnter]
********
System Voltage Optimized
********
SystemVoltageControl [Auto]
x DDR3 Voltage control Auto
x NorthBridge Volt Control Auto
x SouthBridge Volt Control Auto
x CPU NB VID Control Auto
x CPU Voltage Control Auto
Normal CPU Vcore 1.2750V
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
IGXConguration
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
InternalGraphicsMode [UMA]
UMAFrameBufferSize [Auto]
x SurroundView Disabled
VGACoreClockcontrol [Auto]
x VGA Core Clock(MHz) 350
IGXConguration
Internal Graphics Mode
Allows you to determine whether to allocate system memory for the onboard graphics controller.
Disabled Disables the onboard graphics controller.
UMA Allocates memory for the onboard graphics controller from the system memory. (Default)
UMA Frame Buffer Size
Frame buffer size is the total amount of system memory allocated solely for the onboard graphics con-
troller. MS-DOS, for example, will use only this memory for display. Options are: Auto (default), 128MB,
256MB, 512MB.
