- 5 -
GA-H61M-S2PV Motherboard Layout
Box Contents
GA-H61M-S2PV motherboard
Motherboard driver disk Two SATA cables
User's Manual I/O Shield
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
KB_MS
CPU_FAN
LGA1155
ATX
GA-H61M-S2PV
F_AUDIO
AUDIO
B_BIOS
DDR3_1
DDR3_2
BAT
F_PANEL
ATX_12V
Intel
®
H61
SATA2
R_USB
CODEC
CLR_CMOS
M_BIOS
VGADVI
LPT
USB_LAN
PCIEX16
PCI1
PCI2
PCIEX1
F_USB1F_USB2
iTE
IT8728
PCIe to PCI
Bridge
Realtek/
Atheros
GbE LAN
SYS_FANCOM
0
1
2
3
