- 14 -
1-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the
power cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1
2
611
9
3
7
810
1) ATX_12V 7) SATA2 0/1/2/3
2) ATX 8) F_ PANEL
3) CPU_FAN 9) F_ AUDIO
4) SYS_FAN 10) F_USB1/F_USB2
5) BAT 11) COMA
6) GSATA3_0/1 12) CLR_CMOS
5
4
12
To Next Page
