Advanced Frequency Settings

Advanced CPU Core Features

CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Advanced CPU Core Features

: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

CPU Clock Ratio [30X]
CPU Frequency 3.00GHz (100x30)
Intel(R) Turbo Boost Tech.
(Note)
[Auto]
-Turbo Ratio(1-Core)
(Note)
36 [Auto]
-Turbo Ratio(2-Core)
(Note)
34 [Auto]
-Turbo Ratio(3-Core)
(Note)
32 [Auto]
-Turbo Ratio(4-Core)
(Note)
31 [Auto]
-Turbo Power Limit(Watts) 95 [Auto]
-Core Current Limit(Amps) 97 [Auto]
CPU Cores Enabled
(Note)
[All]
CPU Multi-Threading
(Note)
[Enabled]
CPU Enhanced Halt (C1E)
(Note)
[Auto]
C3/C6 State Support
(Note)
[Auto]
CPU Thermal Monitor
(Note)
[Auto]
CPU EIST Function
(Note)
[Auto]
Bi-Directional PROCHOT
(Note)
[Auto]
CPU Clock Ratio
Allows you to alter the clock ratio for the installed CPU. The adjustable range is dependent on the CPU
being installed.
CPU Frequency
Displays the current operating CPU frequency.
Intel(R) Turbo Boost Tech.
(Note)
Allows you to determine whether to enable the Intel CPU Turbo Boost technology. Auto lets the BIOS
automatically congure this setting. (Default: Auto)
Turbo Ratio (1-Core)/(2-Core)/(3-Core)/(4-Core)
(Note)
Allows you to set the CPU Turbo ratios for different number of active cores. Auto sets the CPU Turbo
ratios according to the CPU specications. (Default: Auto)
Turbo Power Limit (Watts)
Allows you to set a power limit for CPU Turbo mode. When the CPU power consumption exceeds the
specied power limit, the CPU will automatically reduce the core frequency in order to reduce the power.
Auto sets the power limit according to the CPU specications. (Default: Auto)
(Note) This item is present only when you install a CPU that supports this feature. For more information
about Intel CPUs' unique features, please visit Intel's website.
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Advanced Frequency Settings
CPU Clock Ratio [30X]
CPU Frequency 3.00GHz (100x30)

Advanced CPU Core Features [Press Enter]
>>>>> Standard Clock Control
BCLK/DMI/PEG Clock Control [Disabled]
x BCLK/DMI/PEG Frequency (0.1MHz) 1000 100.0MHz
System Memory Multiplier (SPD) [Auto]
Memory Frequency (Mhz) 1333 1333
Internal Graphics Clock 1100 [Auto]

: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

