Hardware Installation- 23 -
English
1-8 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the
power cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable
has been securely attached to the connector on the motherboard.
1) ATX_12V_2X
2) ATX (Power Connector)
3) CPU_FAN
4) SYS_FAN1/SYS_FAN2
5) PWR_FAN
6) NB_FAN
7) PCIE_12V
8) FDD
9) IDE
10) SATAII0/1/2/3
11) GSATAII_1/GSATAII_2
12) PWR_LED
13) F_PANEL
14) F_AUDIO
15) CD_IN
16) SPDIF_IN
17) SPDIF_OUT
18) F_USB1/F_USB2
19) F1_1394/F2_1394
20) LPT
21) BATTERY
22) CI
23) CLR_CMOS
2
1
3
19
8
10
9
14
20
15
5
7
13
6
4
4
11
16
17
12
23
18
22
21
To Next Page
