1-2 ProductSpecications
CPU  Support for 7th and 6th generation Intel
®
Core
™
i7 processors/
Intel
®
Core
™
i5 processors/Intel
®
Core
™
i3 processors/
Intel
®
Pentium
®
processors/Intel
®
Celeron
®
processors in the LGA1151 package
(GotoGIGABYTE'swebsiteforthelatestCPUsupportlist.)
 L3 cache varies with CPU
Chipset  Intel
®
Z270 Express Chipset
Memory  4xDDR4DIMMsocketssupportingupto64GBofsystemmemory
 * DuetoaWindows32-bitoperatingsystemlimitation,whenmorethan4GBofphysical
memory is installed, the actual memory size displayed will be less than the size of
the physical memory installed.
 Dual channel memory architecture
 SupportforDDR42133/2400MHzmemorymodules
 SupportforECCUDIMM1Rx8/2Rx8memorymodules(operateinnon-ECCmode)
 Supportfornon-ECCUDIMM1Rx8/2Rx8/1Rx16memorymodules
 SupportforExtremeMemoryProle(XMP)memorymodules
 (GotoGIGABYTE'swebsiteforthelatestsupportedmemoryspeedsandmemory
modules.)
Onboard
Graphics
 Integrated Graphics Processor-Intel
®
HD Graphics support:
- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.2 version.
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
* Support for HDMI 1.4 version.
 Maximum shared memory of 1 GB
Audio  Realtek
®
ALC1220 codec
 Support for Sound Blaster X-Fi MB5
 TINE5532operationalamplier
 HighDenitionAudio
 2/4/5.1/7.1-channel
 Support for S/PDIF Out
LAN  1 x Intel
®
GbELANchip(10/100/1000Mbit)(LAN1)
 1xRivetNetworksKiller
™
E2500LANchip(10/100/1000Mbit)(LAN2)
* Teaming is not supported.
Expansion Slots  1xPCIExpressx16slot,runningatx16(PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
 1xPCIExpressx16slot,runningatx8(PCIEX8)
 * ThePCIEX8slotsharesbandwidthwiththePCIEX16slot.WhenthePCIEX8slot
is populated, the PCIEX16 slot operates at up to x8 mode.
 1xPCIExpressx16slot,runningatx4(PCIEX4)
* The PCIEX4 slot shares bandwidth with the M2P_32G connector. The PCIEX4 slot
operates at up to x2 mode when an SSD is installed in the M2P_32G connector.
 3 x PCI Express x1 slots
* The PCIEX1_3 slot shares bandwidth with the SATA3 1 connector. The SATA3 1
connector becomes unavailable when the PCIEX1_3 is populated.
 (AllofthePCIExpressslotsconformtoPCIExpress3.0standard.)
- 6 -

Gigabyte GA-Z270X-Gaming 5 Specifications

General

Non-ECC	Yes
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666, 2800, 3000, 3200, 3300, 3333, 3400, 3466, 3600, 3666, 3733, 3800, 3866, 4000 MHz
Supported memory module capacities	16GB
Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Component for	PC
Motherboard chipset	Intel® Z270
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
BIOS type	EFI AMI
ACPI version	5.0
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
PCI Express x1 slots	3
Number of M.2 (M) slots	2
Thunderbolt headers	1
Number of SATA II connectors	0
Number of SATA III connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	305 mm
Width	244 mm
