GRAUPNER GR-16 HoTT User Manual

9 / 16
33508_sh_V1
Never connect different battery types or batteries with strongly dif-
ferent charges since this can cause an effect similar to a short circuit.
In such cases for safety reasons, insert voltage stabilizing elements
such as PRX-5A (No. 4136) receiver power supplies between the bat-
teries and receiver.
Attention
When selecting and connecting a power supply, be aware that
although the operating range of the receiver ranges from 3.6 to 8.4
V. However, practically all of the previously marketed servos, speed
controllers, gyros, etc. as well as many which are offered today have
a permissible operating voltage range of 4.8 to 6 V.
binding
To establish a connection with the transmitter, the Graupner HoTT
receiver must first be "bound" to at least one model memory in "its"
Graupner HoTT transmitter. This process is generally called "bind-
ing".
Binding step by step
1. Prepare the transmitter to be bound according to its instructions
for binding.
2. Switch the receiver power supply on.
The LED of the GR-16 HoTT receiver blinks in red with a slow
rhythm.
3. Push and hold for about three seconds the SET button on the
receiver.
After this time has elapsed, the LED flashes red and green simul-
taneously for a further approx. three seconds. During this time,
the receiver is in bind mode.
4. Start the transmitter-side binding according to the instructions
of the transmitter.
5. If the LED of the receiver starts to light constantly green within
approximately three seconds, the binding process has been com-
pleted successfully.
Your transmitter/receiver combination is ready for operation.
If the LED flashes slowly red, the "binding" has failed. Change the
positions of the associated antennas and try the entire proce-
dure again.
Display and adjusting the receiver settings
The settings of the receiver can be displayed with a suitable HoTT
transmitter or the SMART-BOX and some can also be changed. Refer
to the "Telemetry" section for detailed descriptions.
TELEMETRIE
EINSTELLEN,ANZEIGEN
SENSOR
ANZEIGE HF STATUS
AUSWAHL ANSAGEN
RX DATA EIN
ALARMEINSTELLUNG
