Gravely 992023 User Manual

1/00 27
SPECIFICATIONS
Model Number
992020 & 022 992018 992021 992023 992024 992027
Model PM260Z 25 HP
Kohler
with 60" deck
PM260Z 25 HP
Kohler
with 50" deck
PM260Z 22 HP
Robin
with 50" deck
PM250Z 20 HP
Briggs & Stratton
with 50" deck
PM260Z 22 HP
Robin
with 60" deck
PM260Z 25 HP
Kohler
with 72" deck
Length – cm (in) 229 (90) 221 (87) 229 (90)
Height – cm (in) 127 (50)
Width – cm (in) 185 (73) 160 (63) 185 (73) 216 (85)
Weight Actual – kg (lbs) 510 (1125) 499 (1100) 500 (1103) 490 (1080) 511 (1128) 572 (1259)
Battery 12 volt
Brakes Hydro/Dynamic Disk– Parking
Turning Radius 0
Tire Size Front
Rear
15 x 6 - 6
23 x 10.5 - 12
15 x 6 - 6
23 x 8.5 - 12
15 x 6 - 6
23 x 10.5 - 12
Engine – manufacturer
Kohler Kohler Robin Briggs & Stratton Robin Kohler
Model Number
CV25S CV25S EH65V 351777 EH65V CV25S
Cycle
4
Engine Power –
H.P. (KW/min
-1
)
25 H.P.
(18.4 KW/min
-1
)
25 H.P.
(18.4 KW/min
-1
)
22 H.P.
(16.2 KW/min
-1
)
20 H.P.
(14.7 KW/min
-1
)
22 H.P.
(16.2 KW/min
-1
)
25 H.P.
(18.4 KW/min
-1
)
Starting System Electric
Fuel Tank Capacity 9 gals. US (34 liters)
Fuel See Engine Manual
Idle RPM 1800
Governed RPM 3600
Air Cleaner Large Capacity Dual Element
Cooling Capacity Air cooled
Engine oil type See Engine Manual
Spark Plug Gap See Engine Manual
Transmission Hydrostatic Drive
Speed – Forward Max.
Reverse Max.
9 MPH
4.5 MPH
Transmission Lube Mobil 1 15W-50 Synthetic
Drive Clutch Hydrostatic
Tire Pressure Front
Rear
20-25 psi
12-15 psi
Lift System Hydraulic
Power Take Off Electric PTO Clutch/Brake
Mower Deck High Performance
Cutting Width – cm (in) 152 (60) 127 (50) 152 (60) 183 (72)
Cutting Height – cm (in) 2.5 - 12.7 (1 - 5)
Cut Increments – cm (in) Infinite between
2.5 - 12.7 (1 - 5)
