7 - 26
7.5 50" AND 60" MOWER, PROMASTER 200
Mower Removal
1. Lower the mower until the supporting chains are
slack. The deck may need to be on blocks.
2. Remove the key from the ignition switch and the
negative cable from the battery prior to removing
the mower assembly.
3. Release the mower PTO belt tension by removing
tension on the idler pulley rod, Figure 14. Loosen
the two jam nuts and back them off. Remove the
belt.
4. Remove the bolts holding the chains to the mower.
5. Remove the mower mounting pin(s) and move the
mounting arm(s) up.
6. Slide mower out.
NOTE: It may be easier if the lift is raised.
Figure 14
1. Seal
2. Bearing Housing
3. Spindle Shaft
4. Seal
5. Idler Pulley Rod
PF0710
1
2
3
4
Promaster 100, 160
5
5
