Technical Information
Service Manual
3. Outline Dimension Diagram
3.1 Indoor Unit
6 7/64*
W3W2W1
1 11/16
4 36/64*
Φ2 11/64
AGC
D
H
W
Model W H D W1 W2 W3
09K & 12K 32 31/64 11 34/64 7 46/64 4 29/64 21 22/64 6 44/64
18K 38 42/64 12 16/64 8 45/64 4 53/64 27 55/64 5 63/64
24K
42 21/64 13 7/64 9 44/64 7 14/64 27 55/64 7 16/64
* Recommending distances
2 23/64*
Φ2 3/4
W3W2W1
1 11/16
6 57/64*
A
GE
1 11/16
Unit:inch
09K & 12K
24K
18K
Φ2 11/64
7 1/64* 3 32/64*
1 37/64
1 37/64
W3W2W1
