Technical Information
Service Manual
Model
3VIR09HP115V1A
Product Code CB385005800
Power
Supply
Rated Voltage V~ 115
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity Btu/h 9100
Heating Capacity W 10000
Cooling Power Input W 626
Heating Power Input W 715
Cooling Power Current A 6.43
Heating Power Current A 7.42
Rated Input W 1410
Rated Cooling Current A 12.2
Rated Heating Current A 14.36
Air Flow Volume(SS/H/MH/M/ML/L/SL/SM) CFM 353/324/294/265/235/206/194/129
Dehumidifying Volume Pint/h 1.69
EER (Btu/h)/W 14.55
COP (Btu/h)/W 14
SEER 26.5
HSPF 11.2
Application Area yd
2
53-57
Indoor
Unit
Model of indoor unit 3VIR09HP115V1AH
Indoor Unit Product Code CB385N05800
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Φ98X630
Cooling Speed r/min 1300/1200/1100/1000/900/800/750/500
Heating Speed r/min 1300/1200/1100/1000/900/850/800/-
Fan Motor Power Output W 15
Fan Motor RLA A 0.30
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5
Evaporator Row-n Gap mm 2-1.4
Evaporator Coil Length (LXDXW) mm
634 X 22.8 X 304.8
Swing Motor Model MP24AK/MP24BA/MP24HF
Swing Motor Power Output W 1.5/1.5/1.5
Fuse Current A 3.15
Sound Pressure Level dB (A)
Cooling: 40/37/34/31/29/26/24/22
Heating: 41/38/35/31/29/26/25/-
Sound Power Level dB (A)
Cooling: 50/47/44/41/39/36/34/32
Heating: 51/48/45/41/39/36/35/-
Dimension (WXHXD) inch 32 31/64 X 11 34/64 X 7 46/64
Dimension of Carton Box (LXWXH) inch 34 16/64 X 13 47/64 X 10 8/64
Dimension of Package (LXWXH) inch 34 29/64 X 14 24/64 X 10 35/64
Net Weight Ib 20.9
Gross Weight Ib
25.4
2. Specications
2.1 Specication Sheet
