Installation and Maintenance
Service Manual
Step Procedure
4.Remove right side plate, left side plate
Remove the screws xing right side plate, left side
plate and then remove them.
5.Remove axial ow blade
Remove the nut xing the blade and then
remove the axial ow blade.
6.Remove motor and motor support
Remove the screws xing motor and then remove
the motor.
Remove the screws xing motor support and then
remove the motor support.
left side plate
right side plate
axial ow blade
motor support
motor
11. Removal Procedure
