Gree GMV-ND36C/A-T Service Manual

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
17
Panel
dimensions
W×D×
H
mm
670×670
×50
670×670×5
0
670×670×5
0
670×670×5
0
670×670×5
0
670×670×5
0
Net weight
Main
body
kg
20.5
20.5
20.5
20.5
20.5
20.5
Panel
kg
3.5
3.5
3.5
3.5
3.5
3.5
Notes:
① Rated cooling capacity test conditions: indoor 27°C DB/19°C WB, outdoor 35°C DB; connection
pipe length: 5 m, without height drop between units.
② Rated heating capacity test conditions: indoor 20°C DB, outdoor 7°C DB/6 °C WB; connection
pipe length: 5 m, without height drop between units.
3.6 2-way Cassette Type
Model
GMV-
ND28TS/
A-T
GMV-
ND36TS/
A-T
GMV-
ND45TS/
A-T
GMV-
ND50TS/
A-T
GMV-
ND56TS/
A-T
GMV-
ND63TS/
A-T
GMV-
ND71TS/
A-T
Horse Power
HP
1
1.5
2
2
2
2
2.5
Cooling capacity
kW
2.8
3.6
4.5
5.0
5.6
6.3
7.1
Heating capacity
kW
3.2
4.0
5.0
5.6
6.3
7.1
8.0
Air volume
m
3
/h
830
830
830
830
1100
1100
1100
Cooling power input
W
55
55
55
55
103
103
103
Cooling current input
A
0.4
0.4
0.4
0.4
0.7
0.7
0.7
Heating power input
W
55
55
55
55
103
103
103
Heating current input
A
0.4
0.4
0.4
0.4
0.7
0.7
0.7
*Minimum line
current
A
0.5
0.5
0.5
0.5
0.9
0.9
0.9
*Maximum fuse
current
A
6
6
6
6
6
6
6
Sound pressure level
dB(A)
35
35
35
35
39
39
39
Power supply**
220-240V 1 phase ~50Hz/208-230V 1 phase ~60Hz
Piping
interfa
ce
Liquid
pipe
mm
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Φ9.52
Φ9.52
Φ9.52
Gas pipe
mm
Φ9.52
Φ12.7
Φ12.7
Φ12.7
Φ15.9
Φ15.9
Φ15.9
Drain
pipe
External
diameter ×
Thickness
mm
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Main
body
dimens
ions
W×D×H
mm
1200×52
0×340
1200×52
0×340
1200×52
0×340
1200×52
0×340
1200×52
0×340
1200×52
0×340
1200×52
0×340
Panel
dimens
ions
W×D×H
mm
1443×63
0×33
1443×63
0×33
1443×63
0×33
1443×63
0×33
1443×63
0×33
1443×63
0×33
1443×63
0×33
Net
weight
Main body
kg
43.0
43.0
43.0
43.0
46.0
46.0
46.0
Panel
kg
54.0
54.0
54.0
54.0
56.0
56.0
56.0
