Gree GMV-ND36C/A-T Service Manual

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
22
3 dB(A) on this value. The noise in the lowest speed may decrease by about 5 dB(A) on this
value. The recorded noise value of the sample unit is tested in semi-anechoic room. Under
actual installation, the noise value is usually higher than the recorded value of the sample due
to the influence of ambient noise and reflected sound.
3.10 Slim Duct Type
Model
GMV-ND
22PL/B-T
GMV-ND
25PL/B-T
GMV-
ND28PL/
B-T
GMV-
ND32PL/
B-T
GMV-
ND36PL/
B-T
GMV-ND
40PL/B-T
Horse Power
HP
1
1
1
1.5
1.5
1.5
Cooling capacity
kW
2.2
2.5
2.8
3.2
3.6
4.0
Heating capacity
kW
2.5
2.8
3.2
3.6
4.0
4.5
Air volume
m
3
/h
450
450
450
550
550
750
Unit external static pressure
Pa
0/0~15
0/0~15
0/0~15
0/0~15
0/0~15
0/0~15
Cooling power input
W
25
25
25
30
30
35
Cooling current input
A
0.2
0.2
0.2
0.3
0.3
0.3
Heating power input
W
25
25
25
30
30
35
Heating current input
A
0.2
0.2
0.2
0.3
0.3
0.3
*Minimum line current
A
0.25
0.25
0.25
0.38
0.38
0.38
*Maximum fuse current
A
6
6
6
6
6
6
Sound pressure level
dB(A)
30
30
30
31
31
33
Power supply
220-240V 1 phase ~50Hz/208-230V 1 phase ~60Hz
Piping
interface
Liquid pipe
mm
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Gas pipe
mm
Φ9.52
Φ9.52
Φ9.52
Φ12.7
Φ12.7
Φ12.7
Drain pipe
External
diameter ×
thickness
mm
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Dimension
s
W×D×H
mm
710×450×2
00
710×450×
200
710×450
×200
710×450
×200
710×450
×200
1010×450
×200
Net weight
Main body
kg
18.5
18.5
18.5
19.5
19.5
23.5
Model
GMV-
ND45PL/
B-T
GMV-
ND50PL/
B-T
GMV-
ND56PL/
B-T
GMV-
ND63PL/
B-T
GMV-
ND72PL/
B-T
Horse Power
HP
2
2
2
3
3
Cooling capacity
kW
4.5
5.0
5.6
6.3
7.2
Heating capacity
kW
5.0
5.6
6.3
7.1
8.0
Unit external static pressure
Pa
0/0~15
0/0~15
0/0~15
0/0~15
0/0~15
Air volume
m
3
/h
750
750
850
850
1100
Cooling power input
W
35
35
45
45
50
Cooling current input
A
0.3
0.3
0.3
0.3
0.5
Heating power input
W
35
35
45
45
50
