3.13 Wall Mounted type Indoor Unit
Model
GMV-
N22G/A3A-K
GMV-
N28G/A3A-K
GMV-
N36G/A3A-K
GMV-
N45G/A3A-K
GMV-
N50G/A3A-K
Horse Power
HP
1
1
1.5
2
2
Cooling capacity
kW
2.2
2.8
3.6
4.5
5.0
Heating capacity
kW
2.5
3.2
4.0
5.0
5.8
Air volume
m
3
/
h
500
500
630
630
630
Cooling power input
W
50
50
60
60
60
Cooling current input
A
0.2
0.2
0.31
0.31
0.31
Heating power input
W
50
50
60
60
60
Heating current input
A
0.2
0.2
0.31
0.31
0.31
*Minimum line current
A
0.25
0.25
0.38
0.38
0.38
*Maximum fuse current
A
6
6
6
6
6
Sound pressure level
dB(
A)
38
38
44
44
44
Power supply
220-240V 1 phase ~50Hz
Piping
interface
Liquid
pipe
mm
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Gas
pipe
mm
Φ9.52
Φ9.52
Φ12.7
Φ12.7
Φ12.7
Drain pipe
External
diamete
r ×
thicknes
s
mm
Φ20×1.5
Φ20×1.5
Φ20×1.5
Φ20×1.5
Φ20×1.5
Dimensions
W×D×H
mm
843x180x275
843x180x275
940x200x298
940x200x298
940x200x298
Net weight
kg
10
10
12.5
12.5
12.5
Model
GMV-N56G/A3A-K
GMV-N63G/A3A-K
GMV-N71G/A3A-K
Horse Power
HP
2
3
3
Cooling capacity
kW
5.6
6.3
7.1
Heating capacity
kW
6.3
7.0
7.5
Air volume
m
3
/h
750
750
750
Cooling power input
W
70
70
70
Cooling current input
A
0.31
0.31
0.31
Heating power input
W
70
70
70
Heating current input
A
0.31
0.31
0.31
*Minimum line current
A
0.5
0.5
0.5
*Maximum fuse
current
A
6
6
6
Sound pressure level
dB(A)
44
44
44
Power supply
220-240V 1 phase ~50Hz
Piping
interfa
ce
Liquid pipe
mm
Φ9.52
Φ6.35
Φ6.35
Gas pipe
mm
Φ15.9
Φ15.9
Φ15.9
Drain
pipe
External
diameter ×
thickness
mm
Φ30×1.5
Φ30×1.5
Φ30×1.5
Dimen
sions
W×D×H
mm
1128x395x313
1128x395x313
1128x395x313
Net weight
kg
15
15
15
