Air-to-water Heat Pump
10
MONOBLOC
TYPE
1. Diagram of the Operating Principle
Flow
switch
Expansion
Vessel
Automatic
exhaust valve
Tank temp sensor
Water tank
Electric heater
Safety
Note: the swimming pool, solar kit and water mixing accessory are optional parts. When they are required,
please contact the manufacturer.
