Gree GRS-CQ8.0Pd/NhG3-E User Manual

Air-to-water Heat Pump
43
MONOBLOC
TYPE
Silk Screen Introduction
L1-F
Connect to the power supply input of the drive boardL2-F
L3-F
N-F Neutral line for power supply to the main control board
X11 Live line for power supply to the main control board
17.2 Electric wiring
17.2.1 Wiring principle
Refer to Section 16.5.
17.2.2 Terminal board
(1) GRS-CQ4.0Pd/NhG3-E, GRS-CQ6.0Pd/NhG3-E, GRS-CQ4.0Pd/NhG4-E,
GRS-CQ6.0Pd/NhG4-E
