Gree GTH36K3FI User Manual

U-Match Series DC Inverter Service Manual
13
Model
Indoor unit
GTH42K3FI
GTH48K3FI
GTH48K3FI
GTH60K3FI
Product Code
ED020N0710
ED020N0720
ED020N0720
ED020N0730
Outdoor unit
GUHD42NM3FO
GUHD48NK3FO
GUHD48NM3FO
GUHD60NM3FO
Product Code
CF090W0710
CF090W0720
CF090W0730
CF090W0740
Capacity
Cooling Capacity
kW
11.5(3.60-12.50)
14.0(6.00-14.80)
14.0(6.00-14.80)
16.0(7.4~16.5)
Heating Capacity
kW
13.5(3.90-15.50)
16.0(5.20-18.00)
16.0(5.20-18.00)
16.5(6.2~18.5)
PdesignH
kW
10.5
11.8
11.8
12.5
Power Input
Cooling
kW
3.90(0.60-4.70)
4.80(1.40-5.60)
4.80(1.40-5.60)
5.70(1.20-6.90)
Heating
kW
3.70(0.69-4.80)
4.30(1.30-5.50)
4.30(1.30-5.50)
4.60(1.20-6.90)
Design load
Average
SEER / SCOP
W/W
5.6/4.0
5.6/3.8
5.6/4.0
5.1/4.0
Energy Rate(Cooling / Heating)
A+/A+
A+/A
A+/A+
A/A+
Indoor Unit
GTH42K3FI
GTH48K3FI
GTH48K3FI
GTH60K3FI
Power Supply
220-240V~ 50Hz
Heat Exchange
Cross Fin Coil
Cross Fin Coil
Cross Fin Coil
Cross Fin Coil
Fan
Drive
direct
direct
direct
direct
Motor Output
kW
0.14×1
0.19×1
0.19×1
0.20×1
Air Flow
m
3
/h
1900
2300
2300
2500
Sound Pressure Level(SS/H/M/L)
dB(A)
55/54/52/47
56/55/50/46
56/55/50/46
58/56/52/46
Air Filter
Standard washable synthetic
Drain Piping
mm
Φ17×1.75
Φ17×1.75
Φ17×1.75
Φ17×1.75
Outline Dimensions (W×H×D)
mm
1420×245×700
1700×245×700
1700×245×700
1700×245×700
Net Weight
kg
50
59
59
59
Outdoor Unit
GUHD42NM3FO
GUHD48NK3FO
GUHD48NM3FO
GUHD60NM3FO
Power Supply
380-415V 3N~
50Hz
220-240V~ 50Hz
380-415V 3N~ 50Hz
Heat Exchange
Cross Fin Coil
Compressor
Type
Rotary
Rotary
Rotary
Rotary
Power Input
W
4000
4580
4580
4580
Refrigerant
Control
Electronic Expansion Valve
Charge
kg
3.7
4.0
4.0
5.0
Outline Dimensions (W×H×D)
mm
960×1350×410
960×1350×410
960×1350×410
1085×1365×425
Net Weight
kg
108
105
114
126
Piping
Connections
Liquid
Inch
Φ3/8
Φ3/8
Φ3/8
Φ3/8
Gas
Inch
Φ5/8
Φ5/8
Φ5/8
Φ3/4
Max. Length
m
50
50
50
50
Max. Height
m
30
30
30
30

Gree GTH36K3FI Specifications

General

Brand	Gree
Model	GTH36K3FI
Category	Air Conditioner
Language	English
