5
3 PRODUCT DATA
3.1 Product Data of Indoor Unit
3.1.1 Duct Type
Model
Indoor unit
GFH09K3FI
GFH12K3FI
GFH18K3FI
GFH24K3FI
Product Code
CF060N0420
CF060N0430
CF060N0440
CF060N0450
Outdoor unit
GUHD09NK3FO
GUHD12NK3FO
GUHD18NK3FO
GUHD24NK3FO
Product Code
CF090W0630
CF090W0640
CF090W0650
CF090W0660
Capacity
Cooling Capacity
kW
2.7(0.80-3.40)
3.5(0.90-3.70)
5.0(1.60-5.50)
7.0(2.20-8.500)
Heating Capacity
kW
2.9(0.80-3.70)
3.8(0.90-4.10)
5.6(1.40-6.80)
8.0(2.40-9.50)
PdesignH
kW
2.8
3.0
4.5
7.0
Power Input
Cooling
kW
0.84(0.20-1.28)
1.17(0.20-1.40)
1.60(0.55-1.75)
2.18(0.85-2.50)
Heating
kW
0.80(0.20-1.20)
1.05(0.22-1.20)
1.58(0.50-1.90)
2.21(0.80-2.75)
Design load
Average
SEER / SCOP
W/W
5.6/3.8
5.6/4.0
5.6/3.8
6.1/4.0
Energy Rate(Cooling / Heating)
A+/A
A+/A+
A+/A
A++/A+
Indoor Unit
GFH09K3FI
GFH12K3FI
GFH18K3FI
GFH24K3FI
Power Supply
220-240V~ 50Hz
Heat Exchange
Cross Fin Coil
Cross Fin Coil
Cross Fin Coil
Cross Fin Coil
Fan
Drive
direct
direct
direct
direct
Motor Output
kW
0.04×1
0.05×1
0.07×1
0.11×1
Air Flow
m
3
/h
650
750
1000
1400
Rated Ext. Static Pressure
Pa
25
25
25
25
Ext. Static Pressure Range
Pa
0~30
0~30
0~30
0~100
Sound Pressure Level(SS/H/M/L)
dB(A)
36/34/28/26
37/36/34/28
40/39/36/28
47/46/44/40
Air Filter
Standard washable synthetic
Drain
mm
Φ20×1.2
Φ30×1.5
Φ30×1.5
Φ20×1.2
Outline Dimensions (W×H×D)
mm
925×250×665
1035×265×720
1035×265×720
1280×2 70×560
Net Weight
kg
27
33
33
34
Outdoor Unit
GUHD09NK3FO
GUHD12NK3FO
GUHD18NK3FO
GUHD24NK3FO
Power Supply
220-240V~ 50Hz
Heat Exchange
Cross Fin Coil
Compressor
Type
Rotary
Rotary
Rotary
Rotary
Power Input
W
942
942
1440
2550
Refrigerant
Control
Electronic Expansion Valve
Charge
kg
1.2
1.2
1.4
2.2
Outline Dimensions (W×H×D)
mm
850×540×320
850×540×320
955×700×395
980×790×425
Net Weight
kg
34
34
47
67
Piping
Connections
Liquid
Inch
Φ1/4
Φ1/4
Φ1/4
Φ3/8
Gas
Inch
Φ3/8
Φ3/8
Φ1/2
Φ5/8
Max. Length
m
20
20
20
30
Max. Height
m
15
15
15
15
