Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Parameter Unit Value
Model
1.GWH18QD-K3DNA1G 2.GWH18QD-K3DNA5G
3.GWH18QD-K3DNA6G 4.GWH18QD-K3DNB4G
5.GWH18QD-K3DNB6G
Product Code
1.CB419005600 2.CB425003402 CB425003403
3.CB427004400 4.CB434002002
5.CB435000202
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) W 5130(1260~6600)
Heating Capacity(Min~Max) W 5275(1120~6800)
Cooling Power Input(Min~Max) W 1580(380~2450)
Heating Power Input(Min~Max) W 1410(350~2600)
Cooling Current Input A 7.0
Heating Current Input A 6.3
Rated Input W 2600
Rated Current A 11.5
Air Flow Volume(SH/H/M//L/SL) m
3
/h 800/720/610/520/-
Dehumidifying Volume L/h 1.8
EER W/W 3.25
COP W/W 3.74
SEER W/W 6.1
HSPF W/W /
Application Area m
2
23-34
Indoor
Unit
Indoor Unit Model
1.GWH18QD-K3DNA1G/I 2.GWH18QD-K3DNA5G/I
3.GWH18QD-K3DNA6G/I 4.GWH18QD-K3DNB4G/I
5.GWH18QD-K3DNB6G/I
Indoor Unit Product Code
1.CB419N05600 2.CB425N03402 CB425N03403
3.CB427N04400 4.CB434N02002
5.CB435N00202
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Ф106X706
Cooling Speed(SH/H/M//L/SL) r/min 1230/1130/1030/900/-
Heating Speed(SH/H/M//L/SL) r/min 1250/1100/1000/900/-
Fan Motor Power Output W 35
Fan Motor RLA A 0.35
Fan Motor Capacitor μF 2.5
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф7
Evaporator Row-n Gap mm 2-1.4
Evaporator Coil Length (LXDXW) mm 715X25.4X304.8
Swing Motor Model MP35CJ
Swing Motor Power Output W 2.5
Fuse Current A 3.15
Sound Pressure Level(SH/H/M//L/SL) dB (A) 46/42/39/36/-
Sound Power Level(SH/H/M//L/SL) dB (A) 58/54/51/48/-
Dimension (WXHXD) mm 970X300X224
Dimension of Carton Box (LXWXH) mm 1038X380X305
Dimension of Package(LXWXH) mm 1041X383X320
Net Weight kg 13.5
Gross Weight kg 16.5
