Gree SAPPHIRE SAP12HP230V1AH User Manual

2
Technical Information
Service Manual
Product Code CB497000100_L75973
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 50/60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity Btu/h 12000
Heating Capacity Btu/h 12200
Cooling Power Input W 785
Heating Power Input W 940
Cooling Power Current A 3.9
Heating Power Current A 5.3
Rated Input W 1600
Rated Current A 6.5
Air Flow Volume(SH/H/MH/M/ML/L/SL) CFM 500/471/441/353/324/265/235
Dehumidifying Volume Pint/h 2.96
EER (Btu/h)/W 4.48
COP (Btu/h)/W 15.30
SEER 30.5
HSPF 14
Application Area yd
2
19.1-28.7
Indoor Unit
Model of indoor unit SAP12HP230V1AH
Indoor Unit Product Code CB497N00100_L75973
Fan Type Cross-ow
Diameter Length(DXL) inch Φ4 1/6X27 4/5
Fan Motor Cooling Speed (SH/H/MH/M/ML/L/SL/Q) r/min 1400/1300/1200/1100/1000/900/800/550
Fan Motor Heating Speed (SH/H/MH/M/ML/L/SL/Q) r/min 1400/1270/1200/1130/1050/980/900/-
Output of Fan Motor W 60
Fan Motor RLA A 0.09
Fan Motor Capacitor μF /
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ 9/32
Row-n Gap inch 2-1/16
Coil Length (LXDXW) inch 28 9/64X1X12
Swing Motor Model MP35CJ/MP24HF
Output of Swing Motor W 2.5/1.5
Fuse A 3.15
Sound Pressure Level (SH/H/MH/M/ML/L/SL) dB (A) 49/46/43/40/37/34/22
Sound Power Level (SH/H/MH/M/ML/L/SL) dB (A) 59/56/53/50/47/44/32
Dimension (WXHXD) inch 39 53/64X12X8 43/64
Dimension of Carton Box (LXWXH) inch 42 53/64X14 3/4X11 51/64
Dimension of Package (LXWXH) inch 42 1/2X14 7/8X12 13/32
Net Weight Ib 29.8
Gross Weight Ib 36.4
2. Specications
2.1 Specication Sheet

Gree SAPPHIRE SAP12HP230V1AH Specifications

General

Brand	Gree
Model	SAPPHIRE SAP12HP230V1AH
Category	Air Conditioner
Language	English
