Gree SXVD300LCJ2/A-K User Manual

GMV5 Home DC Inverter Multi VRF Units
269
2 The compressor drive board is faulty.
required range;
2 Replace the compressor drive
board.
PJ
Inverter compressor starting
failure
1 The drive board is faulty;
2 The compressor's UVW cable is not
connected properly;
3 The compressor is damaged.
1Replace the compressor drive
board;
2 Reconnect the compressor's
UVW cable;
3Replace the compressor.
C3
Communication failure
between main control board
and variable frequency fan
drive
1The control board is powered off;
2The fan drive board is powered off;
3The communication cable between the
control board and fan drive board is not
connected;
4The fan drive board's dial switch is
wrong.
1Check the power supply of the
control board. Replace the
control board if it works properly;
2Check the power supply of the
drive board. Replace the drive
board if it works properly;
3Connect the main board and
drive board using the
communication cable;
4Adjust the dial switch of the fan
drive board.
H3
Fan drive module reset
protection
1The fan drive board is faulty.
1Replace the fan drive board.
H5
Inverter fan overcurrent
protection
1 The fan drive board's IPM module is
damaged;
2 The fan's UVW cable is not connected
properly;
3 The fan is damaged.
1 Replace the fan drive board;
2 Reconnect the fan's UVW
cable;
3 Replace the fan.
H6
Fan drive IPM module
protection
1 The fan drive board's IPM module is
damaged;
2 The fan's UVW cable is not connected
properly;
3 The fan is damaged.
1 Replace the fan drive board;
2 Reconnect the fan's UVW
cable;
3 Replace the fan.
H7
Fan drive temperature
sensor fault
1The fan drive board is faulty.
1Replace the fan drive board.
H8
Fan drive IPM
over-temperature protection
1 The fan drive board is faulty;
2 Thermal gel is not applied evenly on the
IPM module;
3 The IPM module is not screwed
properly.
1Replace the fan drive board;
2 Apply thermal gel evenly on
the IPM module;
3Screw the IPM module
properly.
H9
Inverter fan out-of-step
protection
The fan drive board is faulty.
Replace the fan drive board.
H
H
Fan drive DC bus high
voltage protection
1 Whether the voltage of the input power
cable of the whole system exceeds 460 V;
2 The fan drive board is faulty.
1Lower the voltage of the input
power cable to the required
range;
2Replace the fan drive board.
