GMV5 Home DC Inverter Multi VRF Units
320
3. Disassemble the oil
separator.
●Unscrew the screws for fixing oil
separator with screwdriver;
●Loosen the electric heating belt in
oil separator;
●Heat up the four connecting
points in oil separator and pull out
the connecting pipe.
Note: Prevent nearby parts from
being burnt during welding.
4. Remove the oil
separator.
●Remove the oil separator from
the chassis.
5. Install a new oil
separator
●Weld the four connecting points
in oil separator.
During welding, the pressure of
nitrogen should be within
0.5±0.1kgf/c ㎡ (relative
pressure).
Note: Prevent nearby parts from
being burnt during welding.
●Install the screws of oil separator.
●Install electric heating belt.
6. Fix and wire the
electric box.
●把 Put the electric box to original
position and screw it up.
●Connect all the wires.
To Next Page
