Central Air Conditioner Thermostat
3
2 Technical parameters
Item Description
Supply voltage AC85~265V 50/60Hz
Temperature setting 16~30°C
Operation temperature 0~50°C
Humidity Relative humidity 5~95% (no condensate)
Load current 2A (resistive load); 1A (inductive load)
Connecting terminal Less than 2.5mm
2
wires
Outline dimensions 86×86×10mm (Width × Height × Thickness)
Protection class IP 30
Installation requirement
An 86x86 unconcealed or concealed standard
junction box with more than 40mm interior height
and standard 60mm hole spacing
3 Components inside the packing box
Item Number
Operating manual 1
Installation screws 2
