9 INSTALL THE HANDLE
1. Take out all components in the packing.
2. Push the bar frame into the grass box tube.
3. Snap the side fastening lugs on the grass box over the bar
frame.
4. Snap the bottom fastening lug on the grass box over the
bar frame.
5. Place the hooks on the rear bag onto the roller shaft.
Secured the bag to the lower handle with the belt.
6. Adjust strap for proper height so the bag does not rub the
ground while mowing or transporting.
10 OPERATION
Align cutting path indication arrow with previously cut path.
NOTE
The width of the machine actual cut is indicated below. Do
not use wheels as a reference point for grass cut line.
10.1 ADJUST THE CUTTING HEIGHT
The machine can be set to different cutting heights.
4
