Groen AH/1E-20 User Manual

Parts Lists (cont'd)
To order parts, contact your Groen Certified Service Agency. Supply the model designation, part
description, part number, quantity and, where applicable, voltage and phase or type of gas.
B. AH/1-60, 80, and 100 Gallon Models
ITEM
NO.
PART
NO.
DESCRIPTION
ITEM
NO.
PART
NO.
DESCRIPTION
1
5471
CAP NUT1/4
--
20 NC
36
9029
VALVE HANDLE (FOR
1
-
1/2"
VALVE)
2 47552 HANDLE 9029 VALVE HANDLE (FOR 2" VALVE)
3 12691 KNOB 12209 VALVE HANDLE (FOR 3" VALVE)
4 12733 SPACER 37 9028 WING NUT (FOR 1-1/2" VALVE)
5 12520 COVER ACTUATOR (60 GAL.) 9028 WING NUT (FOR 2" VALVE)
6 12521 COVER ACTUATOR (80 & 100 GAL.) W/1908 WING NUT (FOR 3" VALVE)
7 2986 PILOT LAMP(115V) 38 8246 BURNER HEAD (PROPANE & NATURAL
GAS)
8 12406 BRACKET (60 GAL) 39 289 STREET ELBOW 2-1/2" IPS
9 12813 BRACKET (80 & 100 GAL.) 40 8774 REDUCER FACE BUSHING 2-1/2" TO 2"
10 99156 PRESSURE GAUGE 41 8731 CLOSE NIPPLE 2" IPS
11 12314 THERMOSTAT KNOB 42 10542 VENTURI ASSY
12 6904 TOGGLE SWITCH 43 — (NOT USED)
13 12313 EA-3 THERMOSTAT 44 399 NATURAL GAS ORIFICE
14 8453 PRESSURE LIMIT CONTROL 45 403 PROPANE GAS ORIFICE
15 10390 RUBBER BOOT FOR ITEM 16 46 396 AIR SHUTTER
16 74665 WARRICK ELECTRODE 47 397 LOCKNUT
17 4010 SAFETY VALVE (units built before 8/1/92) 48 398 END CAP
97009 SAFETY VALVE (units built after 8/1/92) 49 8043 REDUCER FACE BUSHING 1" TO 3/4"
18 4071 1/2" GAUGE GLASS CONNECTOR ASSY. 50 8238 CLOSE NIPPLE 3/4" IPS
(COM.)
19 8917 RUBBER GAUGE GLASS GASKET 51 575 REDUCING TEE
20 WASHER (WITH ASSY. #4071) 52 8504 PIPE PLUG 3/8" IPS
21 HEX NUT (WITH ASSY. #4071) 53 5559 NIPPLE 3/4" IPS X 2-1/2" LG. (60 GAL)
22 8742 WATER GAUGE GLASS 54 8239 NIPPLE 3/4" IPS X 3" LG. (80 GAL)
23 10412 WARRICK RELAY 115V 55 5493 UNION ELBOW 3/4" IPS X 90 DEGREES
24 576 DRAFT DIVERTER 56 8229 NIPPLE 3/4" IPS X 4" LG.
25 4035 COMBUSTION DOOR (COMPLETE) 57 8347 STREET ELBOW 3/4" IPS X 90 DEGREES
4002 HINGE 58 — (NOT USED)
4000 PIN 59 — (NOT USED)
4001 SPRING 60 97610 3/4" BASOTROL GAS VALVE (COMPLETE)
26 4112 KNOB (BLACK PLASTIC) 61 — (NOT USED)
27 8201 INSULATION DOOR (COMPLETE) 62 — (NOT USED)
28 13421 1/2" CONDUIT FITTING 63 345 GAS PRESSURE REGULATOR (NAT. GAS)
29 8902 COVER FOR ITEM #28 3548 GAS PRESSURE REGULATOR
(PROPANE)
30 8904 GASKET FOR ITEM 28 64 8239 NIPPLE 3/4" IPS X 3" LG.
31 9000 1-1/2" DRAW-OFF VALVE (COMPLETE) 65 8172 3/4" IPS GAS COCK
9046 2" DRAW-OFF VALVE (COMPLETE) 66 283 PILOT BRACKET & ORIFICE (NAT. GAS)
12262 3" DRAW-OFF VALVE (COMPLETE) 67 9007 REMOVABLE STRAINER 9" DIA. 1/4"
HOLES
32 9027 VALVE STEM (FOR 1-1/2" VALVE) 68 9040 REMOVABLE STRAINER 9" DIA. 1/8"
HOLES
9048 VALVE STEM (FOR 2" VALVE) 69 9057 REMOVABLE STRAINER 9" DIA. NO
HOLES
1908 3" VALVE STEM (FOR 3" VALVE) 70 69886 PILOT LIGHT SPUD (NATURAL GAS)
33 9024 VALVE BONNET (FOR 1-1/2" VALVE) 71 284 PILOT LIGHT SPUD (PROPANE GAS)
9047 VALVE BONNET (FOR 2" VALVE) 72 63048 THERMOCOUPLE & LEAD
3925 VALVE BONNET (FOR 3" VALVE) 73 13541 WATER FILL ASSY.(units built before 8/1/92)
34 9034 RUBBER "O" RING (FOR 1-1/2" VALVE) 96007 1/2" NPT WATER FILL ASSY. (units built
after 8/1/92)
9034 RUBBER "O' RING (FOR 2" VALVE) 74 10668 3/4" IPS X 90 DEGREE STREET ELBOW
(units built before 8/1/92
W/1908 RUBBER "O" RING (FOR 3" VALVE) 96905 1/2" NPT STREET ELBOW (units built after
8/1/92)
35 8911 SANITARY HEX NUT (FOR 1-1/2" VALVE) 75 2479 BULLET FOOT 1-1/2" TUBE (60 GAL.)
9354 SANITARY HEX NUT (FOR 2" VALVE) 13275 BULLET FOOT 2" TUBE (80 & 100 GAL.)
3927 SANITARY HEX NUT (FOR 3" VALVE) 76 12599 POWER AIDE BRACKET
21
