Groen AH/1E-20 User Manual

Parts List
To order parts, contact your Groen Certified Service Agency. Supply the model designation, part description,
part number, quantity, and, where applicable, voltage and phase or type of gas.
D. AH/1 E-60, 80, and 100 Gallon Models
ITEM
NO.
PART
NO. DESCRIPTION
ITEM
NO.
PART
NO. DESCRIPTION
1
5471
CAP NUT1/4"
-
20 NC
37
9028
WING NUT (FOR
1
-
1/2"
VALVE)
2 47552 HANDLE 9028 WING NUT (FOR 2" VALVE)
3 12691 KNOB W/1908 WING NUT (FOR 3" VALVE)
4 12733 SPACER 38 8246 BURNER HEAD (PROPANE & NATURAL
GAS)
5 12520 COVER ACTUATOR (60 GAL.) 39 289 STREET ELBOW 2-1/2" IPS
6 12521 COVER ACTUATOR (80 & 100 GAL.) 40 8774 REDUCER FACE BUSHING 2-1/2" TO 2"
7 3332 PILOT LIGHT ASSEMBLY (28V) 41 8731 CLOSE NIPPLE 2" IPS
8 12599 BRACKET POWER AIDE 42 10542 VENTURIASSY
9 47552 HANDLE (80 & 100 GAL.) 43 395 MIXER TUBE
10 99156 PRESSURE GAUGE 44 399 NATURAL GAS ORIFICE
11 12314 THERMOSTAT KNOB 45 403 PROPANE GAS ORIFICE
12 6904 TOGGLE SWITCH 46 396 AIR SHUTTER
13 12313 THERMOSTAT 47 397 LOCKNUT
14 8345 PRESSURE LIMIT CONTROL 48 398 END CAP
15 10390 RUBBER BOOT 49 8043 REDUCER FACE BUSHING 1" TO 3/4"
16 74665 WARRICK ELECTRODE 50 — (NOT USED)
17 4010 SAFETY VALVE (units built before 8/1/92) 51 575 REDUCING TEE
97009 SAFETY VALVE (units built after 8/1/92) 52 8504 PIPE PLUG 3/8" IPS
18 4071 1/2- GAUGE GLASS CONNECTOR ASSY. 53 5559 NIPPLE 3/4" IPS X 2-1/2" LG. (60 GAL)
19 8917 RUBBER GAUGE GLASS GASKET 54 8239 NIPPLE 3/4" IPS X 3" LG. (80 GAL)
20 WASHER (WITH ASSY. #4071) 55 5493 UNION ELBOW 3/4" IPS X 90 DEGREE
21 HEX NUT (WITH ASSY. #4071) 56 8229 NIPPLE 3/4" IPS X 4" LG.
22 8742 WATER GAUGE GLASS 57 8751 REDUCING ELBOW 3/4" X 1/2" X 90
DEGREE
23 10412 WARRICK RELAY 115V 58 8877 CLOSE NIPPLE 1/2" IPS
24 576 DRAFT DIVERTER 59 79802 SPRING KIT, PROPANE GAS
25 4035 COMBUSTION DOOR 60 79801 CONTROL VALVE (NAT. GAS)
4002 HINGE 61 5553 NIPPLE 1/2" IPS X 3" LG.
4000 PIN 62 8286 NIPPLE 3/4" IPS X 8" LG.
4001 SPRING 63 — (NOT USED)
26 4112 KNOB 64 — (NOT USED)
27 8201 INSULATION DOOR 65 8172 3/4" IPS GAS COCK
28 13421 1/2" CONDUIT FITTING 66 3750 BURNER & ELECTRODE WITH ORIFICE
(NAT.GAS)
29 8902 COVER FOR ITEM #28 3751 BURNER & ELECTRODE WITH ORIFICE
(PROPANE)
30 8904 COVER FOR ITEM #28 67 9007 REMOVABLE STRAINER 9" DIA. 1/4" HOLES
31 9000 1-1/2" DRAW-OFF VALVE (COMPLETE) 68 9040 REMOVABLE STRAINER 9" DIA 1/8" HOLES
9046 2" DRAW-OFF VALVE (COMPLETE) 69 9057 REMOVABLE STRAINER 9" DIA NO HOLES
12262 3" DRAW-OFF VALVE (COMPLETE) 70 3328 SENSING PROBE WITH KANTHOL
32 9027 VALVE STEM (FOR 1-1/2" VALVE) 71 3329 SENSING PROBE LEAD
9048 VALVE STEM (FOR 2" VALVE) 72 74839 TRANSFORMER (115V/24V)
1908 VALVE STEM (FOR 3" VALVE) 73 13541 WATER FILL ASSEMBLY (units built before
8/1/92)
33 9024 VALVE BONNET (FOR 1-1/2" VALVE) 96007 1/2" NPT WATER FILL ASSY. (units built
after 8/1/92)
9047 VALVE BONNET (FOR 2" VALVE) 74 10668 3/4" IPS X 90 DEGREE STREET ELBOW
(units built before 8/1/92
3925 VALVE BONNET (FOR 3" VALVE) 96905 1/2" NPT STREET ELBOW (units built after
8/1/92)
34 9034 RUBBER "O" RING (FOR 1-1/2" VALVE) 75 2479 BULLET FOOT 1-1/2" TUBE (60 GAL.)
9034 RUBBER “O' RING (FOR 2" VALVE) 13275 BULLET FOOT 2" TUBE (80 & 100 GAL.)
W/1908 RUBBER "O" RING (FOR 3" VALVE) 76 12406 BRACKET HINGE ASSY (60 GAL.)
35 8911 SANITARY HEX NUT (FOR 1-1/2" VALVE) 77 12813 BRACKET HINGE ASSY (80 & 100 GAL.)
9354 SANITARY HEX NUT (FOR 2" VALVE) 78 79803 GAS CONTROL VALVE PROPANE
3927 SANITARY HEX NUT (FOR 3" VALVE)
36 9029 VALVE HANDLE (FOR 1-1/2" VALVE)
9029 VALVE HANDLE (FOR 2" VALVE)
12209 VALVE HANDLE (FOR 3' VALVE)
25

Groen AH/1E-20 Specifications

General

Brand	Groen
Model	AH/1E-20
Category	Kettle
Language	English
