OM/SM-DEE (CE)
23
Parts Lists
Key Description Part No. Key Description Part No.
1 Contactor (See Note) — 26 #10-24 Hex Cap Nut 005470
2 Safety Valve, 50 PSI ¼” NPT 005587 27 Glass Gauge Rod Guard 002981
Safety Valve, 50 PSI ½”NPT 097005 28 ¼” Diameter Roll Pin 1" Long 012614
3 ½” NPT Street Elbow 010668 29 Handle Crank 013617
4 2” Draw-Off Valve, Complete 009000 30 Rubber Grommet 000453
5 Valve Handle 009029 31 Handwheel Shaft ¾” dia 20,40 & 60 013624
6 Wing Nut #10-24 009028 32 Basic Retaining Ring 013483
7 Valve Stem 009027 33 Ball Bearing 009765
Valve Stem 2" 009048 34 Worm Gear 012026
8 Valve Bonnet 009024 35 Warrick Relay 115 Volt 010412
9 Rubber “O” Ring 009034 36 Warrick Relay 220 Volt 010410
10 Sanitary Hex Nut 008911 37 Gear 92 Teeth 3" Bore 013609
Sanitary Hex Nut 2" 009354 38 Socket Set Screw 005097
11 Transformer (480 Volt 3 Phase only) 012827 39 3/8” x 3/8” x 1-3/8” Key Stock 001474
12 #BAF Fuse (480 Volt 3 Phase only) 002651 40 Cylindrical Bearing 009764
13 Pressure Limit Control 096963 41 Grease Fitting 012100
14 Thermostat Knob 013682 42 Gauge Glass Connector (before 011202
15 Electric Thermostat 009730 July 15, 1974)
16 Water Level Electrode (Warrick) 002170 43 ½” 14 NPT Square Plug Head 011146
17 #SC-3 Fuse 002945 (before July 15, 1974)
18 Fuse Holder 002944 44 Indicator Lamp Assembly Complete 008598
19 Indicator Light 250 Volt 016028 (before 1976) 115 Volt
20 Pressure Gauge 001594 45 Indicator Lamp Bulb (before 1976) 001524
21 Sight Glass Fitting 002845 46 Lens, Lamp Red (before 1976) 010894
22 Rubber Gauge Glass Gasket 008917 47 Indicator Lamp Assembly Complete —
23 Washer with Item #21 — (before 1976) 230 Volt
24 Hex nut with Item #21 — 48 Control Housing 002961
25 Water Gauge Glass 4¾” Long 008742 49 Flex Conduit 044770
The following parts are unique to the CE Model DEE Kettle.
Qty. Description Part Qty Description Part No.
1 Tilt Switch & Bracket Assembly 123638 1 Label, incoming power terminal 122006
1 Bracket 014129 1 Label, Wiring Diagram 123492
1 Switch, Micro 002982
1 Insulation Barrier 003490 1 Light, Indicator Red 116381
2 Screw, Rd. Hd. Machine #4-40 003122 2 Light, Indicator Amber 116382
2 Washer, Lock #6 013418 1 Switch, Toggle, CE 122004
2 Nut Hex #4-40 003121
1 Equipotential Terminal Assembly 122021
1 Panel, Controls DEE 123473 1 Label, Equipotential Terminal 113078
1 Water Level Sensor 117737
1 Base Relay Sensor 117738 1 Plug, Hole 002008
1 Contactor 122042
1 Terminal Block 096810 1 Thermostat Knob 122000
1 Fuse Block 077854
1 Fuse 079965 1 Wiring Harness – Power 123555
1 Label, Fuse 102251 1 Wiring Harness – Control 123556
Note: To order a new contactor, specify the part number on the old contactor.
