Page #11 background image
5. Technical data
Supply voltage
24 VDC, - 10 %/+ 10 %.
Power supply is required to be class 2.
Overvoltage category II.
Check that the supply voltage corresponds to the values stated on
the nameplate.
The wires must be rated at minimum 70 °C (158 °F), minimum 18
AWG.
Phase monitoring
Measurement category III.
Pollution degree
Pollution degree 2.
Power
See nameplate.
Ambient temperature
Minimum -30 °C (-22 °F)
Maximum 70 °C (158 °F)
Storage temperature
Minimum
-40 °C (-40 °F)
Maximum 70 °C (158 °F)
Altitude
Maximum 2000 m (6562 ft).
Humidity
5 to 95 %.
Enclosure class
IP20.
Maximum current transformer input
Maximum input current in primary side of current transformer: 72 A.
Turns ratio: 2000:1.
Maximum output current in secondary side of current transformer:
50 mA.
Measurement tolerance: ≤ 5%.
The connection between the primary and secondary current
transformer must be double insulated.
Maximum power dissipation
Object
Maximum power dissipation
99369842 3.8 W
Input/output connections
Signal excitation (excl. EMC) must be limited to -0.5 to 26 VDC or
an effective clamp current less than ±15 mADC.
Relay output, REL 1, REL 2
Maximum load
US: Pilot duty D300.
IEC:
115 VAC: Pick-up = 432 VA. Hold-in = 72 VA
250 VAC: Pick-up = 432 VA. Hold-in = 72 VA
24 VDC: Pick-up = 56 VA. Hold-in = 12 VA. DC-contactors must be
equipped with a transient-voltage-suppression diode of maximum
53 V.
Overvoltage category 3
The relay contacts need to be protected against currents above 8 A
either by use of fuses or class 2 power supply.
Relay output, REL 3, REL 4
250 VAC nominal and 24 VDC nominal mix use.
Nominal current: 10 mA - 2 A AC/DC.
GENIbus terminal
- 7 VDC to + 12 VDC.
Nominal current condition: 4 mADC.
Short-circuit current condition: 328 mA.
Terminal impedance: 120 Ω.
PTC terminals
Trip resistance: greater than 2.2 kΩ +/-5 %.
Automatic reset resistance: less than 1 kΩ +/-5 %.
Response time: 1 second.
DI terminal
Digital input mode
Low logic level below 1.8 V.
High logic level higher than 2.7
V.
ADI terminal
All analogue signals have an out-of-range alarm.
Voltage
0-10 V.
0-5 V.
0 - 3.5 V.
Current
0-20 mA.
4-20 mA.
Temperature
Pt100 2-wire.
Pt1000 2-wire.
Measurement range: -30 to
180 °C (-22 to 356 °F)
Digital input mode
Low logic level below 1.8 V.
High logic level higher than 2.7
V.
Related information
3.6 PTC
6. Disposing of the product
This product or parts of it must be disposed of in an environmentally
sound way.
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest Grundfos company or
service workshop.
The crossed-out wheelie bin symbol on a product
means that it must be disposed of separately from
household waste. When a product marked with this
symbol reaches its end of life, take it to a collection
point designated by the local waste disposal
authorities. The separate collection and recycling of
such products will help protect the environment and
human health.
See also end-of-life information at www.grundfos.com/product-
recycling.
11
English (GB)
